Nichicon 330 μF Surface Mount Polymer Capacitor, 35V
- RS Stock No.:
- 243-7207
- Mfr. Part No.:
- PCR1V331MCL1GS
- Brand:
- Nichicon
Bulk discount available
Subtotal (1 tape of 5 units)*
£15.97
(exc. VAT)
£19.165
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 495 unit(s) shipping from 03 June 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 5 - 45 | £3.194 | £15.97 |
| 50 - 195 | £3.052 | £15.26 |
| 200 + | £2.956 | £14.78 |
*price indicative
- RS Stock No.:
- 243-7207
- Mfr. Part No.:
- PCR1V331MCL1GS
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichicon | |
| Product Type | Polymer Capacitor | |
| Technology | Polymer, Electrolytic | |
| Capacitance | 330μF | |
| Voltage | 35V | |
| Mount Type | Surface Mount | |
| Lead Pitch | 4.6mm | |
| Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Dimensions | 10 x 12.7 mm | |
| Series | PCR | |
| Depth | 10.3mm | |
| Height | 10.3mm | |
| Length | 12.6mm | |
| Electrolyte Type | Solid | |
| Automotive Standard | AEC-Q200 | |
| Lifetime | 4000 h | |
| Diameter | 10mm | |
| Minimum Operating Temperature | -55°C | |
| Dissipation Factor | 0.08% | |
| Ripple Current | 3900mA | |
| Leakage Current | 346μA | |
| Select all | ||
|---|---|---|
Brand Nichicon | ||
Product Type Polymer Capacitor | ||
Technology Polymer, Electrolytic | ||
Capacitance 330μF | ||
Voltage 35V | ||
Mount Type Surface Mount | ||
Lead Pitch 4.6mm | ||
Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Dimensions 10 x 12.7 mm | ||
Series PCR | ||
Depth 10.3mm | ||
Height 10.3mm | ||
Length 12.6mm | ||
Electrolyte Type Solid | ||
Automotive Standard AEC-Q200 | ||
Lifetime 4000 h | ||
Diameter 10mm | ||
Minimum Operating Temperature -55°C | ||
Dissipation Factor 0.08% | ||
Ripple Current 3900mA | ||
Leakage Current 346μA | ||
- COO (Country of Origin):
- JP
The Nichicon's PCR series is chip type polymer capacitor have high reliability, low ESR and provides high ripple current, high voltage.
High reliability, High voltage (to 80V)
Low ESR, High ripple current
Long life of 4000 hours at 125°C
SMD type : Lead free reflow soldering condition at 260°C peak complete correspondence
Compliant to the RoHS directive (2011/65/EU,(EU)2015/863)
ESR after
