CHEMI-CON 150 μF Surface Mount Polymer Capacitor, 35 V
- RS Stock No.:
- 251-4899
- Mfr. Part No.:
- HHXC350ARA151MHA0G
- Brand:
- CHEMI-CON
Subtotal (1 box of 500 units)*
£233.00
(exc. VAT)
£279.50
(inc. VAT)
Add 500 units to get free delivery
Temporarily out of stock
- Shipping from 01 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 500 + | £0.466 | £233.00 |
*price indicative
- RS Stock No.:
- 251-4899
- Mfr. Part No.:
- HHXC350ARA151MHA0G
- Brand:
- CHEMI-CON
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CHEMI-CON | |
| Technology | Electrolytic | |
| Product Type | Polymer Capacitor | |
| Capacitance | 150μF | |
| Voltage | 35 V | |
| Mount Type | Surface Mount | |
| Package/Case | HA0 | |
| Lead Pitch | 3.1mm | |
| Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Dimensions | 8 x 10 mm | |
| Depth | 5.3mm | |
| Height | 5.3mm | |
| Length | 10mm | |
| Series | HXC | |
| Electrolyte Type | Hybrid | |
| Leakage Current | 3μA | |
| Ripple Current | 1.6mA | |
| Minimum Operating Temperature | -55°C | |
| Automotive Standard | AEC-Q200 | |
| Dissipation Factor | 0.12% | |
| Anti Vibration | Yes | |
| Diameter | 8 mm | |
| Select all | ||
|---|---|---|
Brand CHEMI-CON | ||
Technology Electrolytic | ||
Product Type Polymer Capacitor | ||
Capacitance 150μF | ||
Voltage 35 V | ||
Mount Type Surface Mount | ||
Package/Case HA0 | ||
Lead Pitch 3.1mm | ||
Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Dimensions 8 x 10 mm | ||
Depth 5.3mm | ||
Height 5.3mm | ||
Length 10mm | ||
Series HXC | ||
Electrolyte Type Hybrid | ||
Leakage Current 3μA | ||
Ripple Current 1.6mA | ||
Minimum Operating Temperature -55°C | ||
Automotive Standard AEC-Q200 | ||
Dissipation Factor 0.12% | ||
Anti Vibration Yes | ||
Diameter 8 mm | ||
- COO (Country of Origin):
- JP
The Nippon Chemi-Con HXC Hybrid Polymer Aluminum Electrolytic Capacitors provide 4000 hours operation at +125℃ and serve high frequency and harsh environment applications.This SMD type hybrid capacitor guarantees use at 125℃ and is a general-purpose product that can be used in a wide range of applications, including home appliances, industrial equipment, and automotive electronics.
High ripple current model is now available for JC5 size
High reliability and high voltage are realized by hybrid electrolyte
Endurance with ripple current 4,000 hours at 125°C
Rated voltage range 16 to 80Vdc
Capacitance range 68 to 560μF
