Panasonic 100μF Through Hole Polymer Capacitor, 63V dc
- RS Stock No.:
- 210-5956
- Mfr. Part No.:
- EEHZS1J101V
- Brand:
- Panasonic
Bulk discount available
Subtotal (1 tape of 2 units)*
£2.98
(exc. VAT)
£3.58
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1,046 unit(s) ready to ship
- Plus 999,998,952 unit(s) shipping from 26 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 2 - 8 | £1.49 | £2.98 |
| 10 - 48 | £1.36 | £2.72 |
| 50 - 98 | £1.16 | £2.32 |
| 100 - 198 | £0.995 | £1.99 |
| 200 + | £0.87 | £1.74 |
*price indicative
- RS Stock No.:
- 210-5956
- Mfr. Part No.:
- EEHZS1J101V
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Technology | Hybrid | |
| Capacitance | 100µF | |
| Voltage | 63V dc | |
| Mounting Type | Through Hole | |
| Equivalent Series Resistance | 19mΩ | |
| Tolerance | ±20% | |
| Length | 12.8mm | |
| Maximum Operating Temperature | +125°C | |
| Dimensions | 10 x 12.8mm | |
| Series | ZS | |
| Ripple Current | 3000mA | |
| Minimum Operating Temperature | -55°C | |
| Lifetime | 4000h | |
| Dissipation Factor | 12% | |
| Leakage Current | 63 μA | |
| Polarised | Polar | |
| Diameter | 10mm | |
Select all | ||
|---|---|---|
Brand Panasonic | ||
Technology Hybrid | ||
Capacitance 100µF | ||
Voltage 63V dc | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 19mΩ | ||
Tolerance ±20% | ||
Length 12.8mm | ||
Maximum Operating Temperature +125°C | ||
Dimensions 10 x 12.8mm | ||
Series ZS | ||
Ripple Current 3000mA | ||
Minimum Operating Temperature -55°C | ||
Lifetime 4000h | ||
Dissipation Factor 12% | ||
Leakage Current 63 μA | ||
Polarised Polar | ||
Diameter 10mm | ||
- COO (Country of Origin):
- JP
The Panasonic ZS series conductive polymer hybrid aluminium electrolytic capacitor used vibration-proof of ±20 % tolerance and has 63 V voltage. It has 100μF of capacitance which size code is G12 and ultra low ESR between 13 mΩ and 19 mΩ.
Endurance 4000 h at 125 ℃
High ripple current and high capacitance
High-withstand voltage (to 63 V), low leakage current (0.01 CV or 3 μF)
Vibration-proof product is available upon request.
High ripple current and high capacitance
High-withstand voltage (to 63 V), low leakage current (0.01 CV or 3 μF)
Vibration-proof product is available upon request.
