Panasonic 150 μF Through Hole Polymer Capacitor, 50 V
- RS Stock No.:
- 210-5949
- Mfr. Part No.:
- EEHZS1H151P
- Brand:
- Panasonic
Bulk discount available
Subtotal (1 tape of 2 units)*
£3.20
(exc. VAT)
£3.84
(inc. VAT)
Add 36 units to get free delivery
In Stock
- 414 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 2 - 8 | £1.60 | £3.20 |
| 10 - 48 | £1.44 | £2.88 |
| 50 - 98 | £1.175 | £2.35 |
| 100 - 198 | £1.095 | £2.19 |
| 200 + | £1.045 | £2.09 |
*price indicative
- RS Stock No.:
- 210-5949
- Mfr. Part No.:
- EEHZS1H151P
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Technology | Hybrid | |
| Product Type | Polymer Capacitor | |
| Capacitance | 150μF | |
| Voltage | 50 V | |
| Mount Type | Through Hole | |
| Polarity | Polar | |
| Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Dimensions | 10 x 12.5 mm | |
| Height | 11mm | |
| Series | ZS | |
| Length | 12.5mm | |
| Electrolyte Type | Hybrid | |
| Diameter | 10 mm | |
| Leakage Current | 75μA | |
| Ripple Current | 3.2A | |
| Lifetime | 4000 h | |
| Minimum Operating Temperature | -55°C | |
| Automotive Standard | AEC-Q200 | |
| Dissipation Factor | 10% | |
| Select all | ||
|---|---|---|
Brand Panasonic | ||
Technology Hybrid | ||
Product Type Polymer Capacitor | ||
Capacitance 150μF | ||
Voltage 50 V | ||
Mount Type Through Hole | ||
Polarity Polar | ||
Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Dimensions 10 x 12.5 mm | ||
Height 11mm | ||
Series ZS | ||
Length 12.5mm | ||
Electrolyte Type Hybrid | ||
Diameter 10 mm | ||
Leakage Current 75μA | ||
Ripple Current 3.2A | ||
Lifetime 4000 h | ||
Minimum Operating Temperature -55°C | ||
Automotive Standard AEC-Q200 | ||
Dissipation Factor 10% | ||
- COO (Country of Origin):
- JP
The Panasonic ZS series conductive polymer hybrid aluminium electrolytic capacitor has ±20 % tolerance and used 50 V voltage. It has 150μF of capacitance which size code is G12 and ultra low ESR between 13 mΩ and 19 mΩ.
Endurance 4000 h at 125 ℃
High ripple current and high capacitance
High-withstand voltage (to 63 V), low leakage current (0.01 CV or 3 μF)
Vibration-proof product is available upon request.
