Panasonic 150μF Through Hole Polymer Capacitor, 50V dc
- RS Stock No.:
- 210-5948
- Mfr. Part No.:
- EEHZS1H151P
- Brand:
- Panasonic
Subtotal (1 reel of 400 units)*
£280.80
(exc. VAT)
£336.80
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 400 unit(s) shipping from 09 February 2026
- Plus 999,999,200 unit(s) shipping from 06 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
---|---|---|
400 + | £0.702 | £280.80 |
*price indicative
- RS Stock No.:
- 210-5948
- Mfr. Part No.:
- EEHZS1H151P
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Panasonic | |
Technology | Hybrid | |
Capacitance | 150µF | |
Voltage | 50V dc | |
Mounting Type | Through Hole | |
Equivalent Series Resistance | 17mΩ | |
Tolerance | ±20% | |
Length | 12.5mm | |
Maximum Operating Temperature | +125°C | |
Dimensions | 10 x 12.5mm | |
Series | ZS | |
Leakage Current | 75 μA | |
Minimum Operating Temperature | -55°C | |
Diameter | 10mm | |
Polarised | Polar | |
Dissipation Factor | 10% | |
Lifetime | 4000h | |
Ripple Current | 3.2A | |
Select all | ||
---|---|---|
Brand Panasonic | ||
Technology Hybrid | ||
Capacitance 150µF | ||
Voltage 50V dc | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 17mΩ | ||
Tolerance ±20% | ||
Length 12.5mm | ||
Maximum Operating Temperature +125°C | ||
Dimensions 10 x 12.5mm | ||
Series ZS | ||
Leakage Current 75 μA | ||
Minimum Operating Temperature -55°C | ||
Diameter 10mm | ||
Polarised Polar | ||
Dissipation Factor 10% | ||
Lifetime 4000h | ||
Ripple Current 3.2A | ||
- COO (Country of Origin):
- JP
The Panasonic ZS series conductive polymer hybrid aluminium electrolytic capacitor has ±20 % tolerance and used 50 V voltage. It has 150μF of capacitance which size code is G12 and ultra low ESR between 13 mΩ and 19 mΩ.
Endurance 4000 h at 125 ℃
High ripple current and high capacitance
High-withstand voltage (to 63 V), low leakage current (0.01 CV or 3 μF)
Vibration-proof product is available upon request.
High ripple current and high capacitance
High-withstand voltage (to 63 V), low leakage current (0.01 CV or 3 μF)
Vibration-proof product is available upon request.
