Panasonic 120 μF Surface Polymer Capacitor, 50V dc
- RS Stock No.:
- 179-9287
- Mfr. Part No.:
- EEHZC1H121P
- Brand:
- Panasonic
Subtotal (1 pack of 5 units)*
£9.67
(exc. VAT)
£11.605
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 905 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 + | £1.934 | £9.67 |
*price indicative
- RS Stock No.:
- 179-9287
- Mfr. Part No.:
- EEHZC1H121P
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Product Type | Polymer Capacitor | |
| Technology | Hybrid | |
| Capacitance | 120μF | |
| Voltage | 50V dc | |
| Mount Type | Surface | |
| Polarity | Polar | |
| Lead Pitch | 4.6mm | |
| Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Dimensions | 10 (Dia) x 10.2 mm | |
| Length | 10.2mm | |
| Height | 12mm | |
| Series | ZC | |
| Electrolyte Type | Hybrid | |
| Dissipation Factor | 0.1% | |
| Diameter | 10mm | |
| Automotive Standard | AEC-Q200 | |
| Lifetime | 1000 h | |
| Minimum Operating Temperature | -55°C | |
| Ripple Current | 1.6A | |
| Leakage Current | 60μA | |
| Select all | ||
|---|---|---|
Brand Panasonic | ||
Product Type Polymer Capacitor | ||
Technology Hybrid | ||
Capacitance 120μF | ||
Voltage 50V dc | ||
Mount Type Surface | ||
Polarity Polar | ||
Lead Pitch 4.6mm | ||
Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Dimensions 10 (Dia) x 10.2 mm | ||
Length 10.2mm | ||
Height 12mm | ||
Series ZC | ||
Electrolyte Type Hybrid | ||
Dissipation Factor 0.1% | ||
Diameter 10mm | ||
Automotive Standard AEC-Q200 | ||
Lifetime 1000 h | ||
Minimum Operating Temperature -55°C | ||
Ripple Current 1.6A | ||
Leakage Current 60μA | ||
- COO (Country of Origin):
- JP
Panasonic Polymer Capacitor, 120μF Capacitance, 50V Voltage - EEHZC1H121P
This polymer capacitor is a surface-mount electrolytic component designed for demanding electronic and automotive control systems. It provides decoupling and energy storage at medium voltage levels while tolerating elevated temperatures and continuous ripple conditions, making it suitable for Compact assemblies in industrial automation and vehicle electronics.
Features and Benefits:
• 120μF capacitance delivers stable bulk storage for power rails
• 50V rated voltage supports medium-voltage circuits safely
• 125°C maximum temperature allows high‑temperature operation
• 1.6A ripple current handles substantial AC stress on supply lines
• 60μA leakage current minimises standby losses in long duty cycles
• ±20% tolerance offers predictable performance across batches
• 50V rated voltage supports medium-voltage circuits safely
• 125°C maximum temperature allows high‑temperature operation
• 1.6A ripple current handles substantial AC stress on supply lines
• 60μA leakage current minimises standby losses in long duty cycles
• ±20% tolerance offers predictable performance across batches
Applications
• Suitable for automotive power-supply smoothing in ECUs
• Ideal for DC to DC converter output filtering in automation equipment
• Used with motor drive electronics requiring high ripple handling
• Can be used for backup power buffering in control modules
• Ideal for DC to DC converter output filtering in automation equipment
• Used with motor drive electronics requiring high ripple handling
• Can be used for backup power buffering in control modules
What mounting considerations apply for PCBA assembly?
It is a surface-mount device supplied in taping format and requires solder pads matching its lead pitch for reliable reflow placement.
How long can it operate continuously at elevated temperatures?
The component is specified for a lifetime of 4000h when subjected to its rated operating conditions, including high-temperature ambient.
What environmental temperature range can it tolerate during operation?
It will function across a wide span from -55°C up to its 125°C maximum operating temperature.
How does polarity affect installation and circuit design?
The device is polarised, so correct orientation on the board is essential to prevent malfunction or damage when exposed to rated voltages.
What physical envelope and package type does it require on the PCB?
The component has a nominal diameter of 10mm and a height of 12 mm, and is packaged for surface-mount placement.
