KEMET 150μF Through Hole Polymer Capacitor, 63V dc
- RS Stock No.:
- 179-7227
- Mfr. Part No.:
- A759MW157M1JEAE048
- Brand:
- KEMET
Bulk discount available
Subtotal (1 pack of 2 units)*
£3.69
(exc. VAT)
£4.428
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 202 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
2 - 18 | £1.845 | £3.69 |
20 - 48 | £1.745 | £3.49 |
50 - 98 | £1.62 | £3.24 |
100 - 198 | £1.51 | £3.02 |
200 + | £1.365 | £2.73 |
*price indicative
- RS Stock No.:
- 179-7227
- Mfr. Part No.:
- A759MW157M1JEAE048
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | KEMET | |
Technology | Electrolytic | |
Capacitance | 150µF | |
Voltage | 63V dc | |
Dielectric Material Family | Aluminium | |
Mounting Type | Through Hole | |
Equivalent Series Resistance | 48mΩ | |
Lead Pitch | 5mm | |
Tolerance | ±20% | |
Length | 31mm | |
Height | 16mm | |
Maximum Operating Temperature | +125°C | |
Dimensions | 10 (Dia) x 16mm | |
Series | A759 | |
Electrolyte Type | Solid | |
Polarised | Polar | |
Leakage Current | 1.418 mA | |
Lifetime | 2000h | |
Minimum Operating Temperature | -55°C | |
Ripple Current | 2.61A | |
Dissipation Factor | 12% | |
Diameter | 10mm | |
Select all | ||
---|---|---|
Brand KEMET | ||
Technology Electrolytic | ||
Capacitance 150µF | ||
Voltage 63V dc | ||
Dielectric Material Family Aluminium | ||
Mounting Type Through Hole | ||
Equivalent Series Resistance 48mΩ | ||
Lead Pitch 5mm | ||
Tolerance ±20% | ||
Length 31mm | ||
Height 16mm | ||
Maximum Operating Temperature +125°C | ||
Dimensions 10 (Dia) x 16mm | ||
Series A759 | ||
Electrolyte Type Solid | ||
Polarised Polar | ||
Leakage Current 1.418 mA | ||
Lifetime 2000h | ||
Minimum Operating Temperature -55°C | ||
Ripple Current 2.61A | ||
Dissipation Factor 12% | ||
Diameter 10mm | ||
- COO (Country of Origin):
- CN
KEMETs A759 Single-Ended Conductive Polymer Aluminum Solid Electrolytic Capacitors offer longer life and greater stability across a wide range of temperatures. The A759 highly conductive solid polymer electrolyte eliminates the risk of explosion from drying out and due to its low ESR properties, is able to withstand higher ripple currents during normal operation. The A759 is ideally suited for industrial and commercial applications.
Applications
Typical applications include long life LED drivers,
professional power amplifiers and industrial power supplies.
Benefits
Through-hole form factor
High voltage
Low impedance
High ripple current
125°C/2,000 hours
Typical applications include long life LED drivers,
professional power amplifiers and industrial power supplies.
Benefits
Through-hole form factor
High voltage
Low impedance
High ripple current
125°C/2,000 hours
