KEMET 56 μF Through Hole Polymer Capacitor, 80 V dc
- RS Stock No.:
- 179-7202
- Mfr. Part No.:
- A759MS566M1KAAE045
- Brand:
- KEMET
Bulk discount available
Subtotal (1 bag of 250 units)*
£285.00
(exc. VAT)
£342.50
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 03 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 250 - 250 | £1.14 | £285.00 |
| 500 + | £1.109 | £277.25 |
*price indicative
- RS Stock No.:
- 179-7202
- Mfr. Part No.:
- A759MS566M1KAAE045
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KEMET | |
| Product Type | Polymer Capacitor | |
| Technology | Electrolytic | |
| Capacitance | 56μF | |
| Voltage | 80 V dc | |
| Mount Type | Through Hole | |
| Polarity | Polar | |
| Lead Pitch | 5mm | |
| Tolerance | ±20 % | |
| Maximum Operating Temperature | 125°C | |
| Dimensions | 10 (Dia) x 12 mm | |
| Length | 31mm | |
| Height | 12mm | |
| Series | A759 | |
| Electrolyte Type | Solid | |
| Leakage Current | 672μA | |
| Ripple Current | 2.63A | |
| Minimum Operating Temperature | -55°C | |
| Dissipation Factor | 12% | |
| Automotive Standard | No | |
| Lifetime | 2000 h | |
| Diameter | 10 mm | |
| Select all | ||
|---|---|---|
Brand KEMET | ||
Product Type Polymer Capacitor | ||
Technology Electrolytic | ||
Capacitance 56μF | ||
Voltage 80 V dc | ||
Mount Type Through Hole | ||
Polarity Polar | ||
Lead Pitch 5mm | ||
Tolerance ±20 % | ||
Maximum Operating Temperature 125°C | ||
Dimensions 10 (Dia) x 12 mm | ||
Length 31mm | ||
Height 12mm | ||
Series A759 | ||
Electrolyte Type Solid | ||
Leakage Current 672μA | ||
Ripple Current 2.63A | ||
Minimum Operating Temperature -55°C | ||
Dissipation Factor 12% | ||
Automotive Standard No | ||
Lifetime 2000 h | ||
Diameter 10 mm | ||
- COO (Country of Origin):
- CN
KEMET’s A759 Single-Ended Conductive Polymer Aluminum Solid Electrolytic Capacitors offer longer life and greater stability across a wide range of temperatures. The A759 highly conductive solid polymer electrolyte eliminates the risk of explosion from drying out and due to its low ESR properties, is able to withstand higher ripple currents during normal operation. The A759 is ideally suited for industrial and commercial applications.
Applications
Typical applications include long life LED drivers,
professional power amplifiers and industrial power supplies.
Benefits
Through-hole form factor
High voltage
Low impedance
High ripple current
125°C/2,000 hours
