Molex 39543 Series Pluggable Terminal Block, 10-Contact, 5 mm Pitch, 1 Row, 39543-3010
- RS Stock No.:
- 684-416
- Mfr. Part No.:
- 39543-3010
- Brand:
- Molex
Subtotal (1 pack of 60 units)*
£194.91
(exc. VAT)
£233.89
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 18 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £194.91 | £3.249 |
*price indicative
- RS Stock No.:
- 684-416
- Mfr. Part No.:
- 39543-3010
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Number of Contacts | 10 | |
| Product Type | Pluggable Terminal Block | |
| Pitch | 5mm | |
| Current | 10A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 0.2mm² | |
| Maximum Wire Size mm² | 2.08mm² | |
| Minimum Wire Size AWG | 14AWG | |
| Maximum Wire Size AWG | 24AWG | |
| Orientation | Vertical | |
| Colour | Black | |
| Wire Connection Method | PCB Terminal Blocks and Connector | |
| Voltage | 300V | |
| Series | 39543 | |
| Standards/Approvals | RoHS, IPC 1752A Class C, IPC 1752A Class D, Low-Halogen, REACH | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Number of Contacts 10 | ||
Product Type Pluggable Terminal Block | ||
Pitch 5mm | ||
Current 10A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 0.2mm² | ||
Maximum Wire Size mm² 2.08mm² | ||
Minimum Wire Size AWG 14AWG | ||
Maximum Wire Size AWG 24AWG | ||
Orientation Vertical | ||
Colour Black | ||
Wire Connection Method PCB Terminal Blocks and Connector | ||
Voltage 300V | ||
Series 39543 | ||
Standards/Approvals RoHS, IPC 1752A Class C, IPC 1752A Class D, Low-Halogen, REACH | ||
- COO (Country of Origin):
- CN
The Molex Eurostyle Fixed Mount PCB Terminal Block is a highly efficient connector designed for seamless wire-to-board applications. This terminal block features a 5.00mm pitch and offers a robust construction with 10 circuits for effective connectivity. With a vertical orientation and horizontal entry angle, the design ensures easy installation and stability on PCBs. Engineered from durable black resin, it operates effectively within a temperature range of -40° to +105°C, making it suitable for diverse environments. Its low-halogen status adds to its appeal for environmentally conscious applications, ensuring compliance with key industry standards.
Compatible with a wide range of wire sizes from AWG 14 to 22
Lead-free solder process capability simplifies assembly
EP compliant with EU regulations, promoting environmental responsibility
Mated parts are non-polarized, allowing for flexible design implementations
