Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£155.06
(exc. VAT)
£186.07
(inc. VAT)
- RS Stock No.:
- 514-732
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Colour | Black | |
Length | 300mm | |
Material | PEEK | |
Form | Rod | |
Rod Diameter | 20mm | |
Density | 1.44g/cm³ | |
Tensile Strength | 215 MPa | |
Flammability Rating | UL 94 V-0 | |
Maximum Operating Temperature | +260°C | |
Water Absorption | 0.1% | |
Hardness | 255 Ball Indentation | |
Elongation | 1.5% | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Colour Black | ||
Length 300mm | ||
Material PEEK | ||
Form Rod | ||
Rod Diameter 20mm | ||
Density 1.44g/cm³ | ||
Tensile Strength 215 MPa | ||
Flammability Rating UL 94 V-0 | ||
Maximum Operating Temperature +260°C | ||
Water Absorption 0.1% | ||
Hardness 255 Ball Indentation | ||
Elongation 1.5% | ||
- COO (Country of Origin):
- DE
PEEK CF30
PEEK CF30 is a 30% carbon fibre reinforced semi-crystalline, high performance thermoplastic for extremely demanding applications. Suitable for use in Mechanical engineering, automotive industry, nuclear and vacuum technology, transport and conveyor technology, textile , packaging and paper processing machinery, precision engineering, chemical engineering, aircraft and aerospace industries
High thermal mechanical strength
Excellent creep resistance
good chemical resistance
Hydrolysis resistant
Excellent rigidity
High dimensional stability
Excellent wear resistance
Not electrically insulating
Flame retardant UL94 V-0
Excellent creep resistance
good chemical resistance
Hydrolysis resistant
Excellent rigidity
High dimensional stability
Excellent wear resistance
Not electrically insulating
Flame retardant UL94 V-0
