Bulk discount available
Subtotal (1 lot of 1 unit)*
£74.65
(exc. VAT)
£89.58
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 21 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Lot(s) | Per Lot |
---|---|
1 - 2 | £74.65 |
3 - 9 | £69.42 |
10 - 29 | £65.71 |
30 + | £59.80 |
*price indicative
- RS Stock No.:
- 139-546
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Colour | White | |
Length | 1m | |
Material | Acetal | |
Form | Rod | |
Rod Diameter | 50mm | |
Density | 1.41g/cm³ | |
Tensile Strength | 60 MPa | |
Maximum Operating Temperature | +100°C | |
Flammability Rating | UL 94 HB | |
Polymer Type | Copolymer | |
Thermal Conductivity | 0.31W/mK | |
Water Absorption | 0.5% | |
Elongation | 30% | |
Suitability | Friction Bearing & Strips, Gears, Housing Parts, Rollers & Insulators | |
Melting Point | +165°C | |
Hardness | M 86 Rockwell | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Colour White | ||
Length 1m | ||
Material Acetal | ||
Form Rod | ||
Rod Diameter 50mm | ||
Density 1.41g/cm³ | ||
Tensile Strength 60 MPa | ||
Maximum Operating Temperature +100°C | ||
Flammability Rating UL 94 HB | ||
Polymer Type Copolymer | ||
Thermal Conductivity 0.31W/mK | ||
Water Absorption 0.5% | ||
Elongation 30% | ||
Suitability Friction Bearing & Strips, Gears, Housing Parts, Rollers & Insulators | ||
Melting Point +165°C | ||
Hardness M 86 Rockwell | ||
- COO (Country of Origin):
- DE
Acetal Copolymer
Low moisture absorption and good chemical resistance with excellent mechanical strength. Dimensionally stable, suitable for close tolerance components, bearings, bushes, gears, valves and valve seatings. White in colour
Standards
DIN 50 014
Acetal Copolymer & Homopolymer
