Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
1 Lot of 1
£71.22
(exc. VAT)
£85.46
(inc. VAT)
- RS Stock No.:
- 139-518
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Colour | White | |
| Length | 1m | |
| Material | Acetal | |
| Form | Rod | |
| Rod Diameter | 36mm | |
| Density | 1.41g/cm³ | |
| Tensile Strength | 60 MPa | |
| Flammability Rating | UL 94 HB | |
| Maximum Operating Temperature | +100°C | |
| Polymer Type | Copolymer | |
| Hardness | M 86 Rockwell | |
| Suitability | Friction Bearing & Strips, Gears, Housing Parts, Rollers & Insulators | |
| Thermal Conductivity | 0.31W/mK | |
| Melting Point | +165°C | |
| Water Absorption | 0.5% | |
| Elongation | 30% | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Colour White | ||
Length 1m | ||
Material Acetal | ||
Form Rod | ||
Rod Diameter 36mm | ||
Density 1.41g/cm³ | ||
Tensile Strength 60 MPa | ||
Flammability Rating UL 94 HB | ||
Maximum Operating Temperature +100°C | ||
Polymer Type Copolymer | ||
Hardness M 86 Rockwell | ||
Suitability Friction Bearing & Strips, Gears, Housing Parts, Rollers & Insulators | ||
Thermal Conductivity 0.31W/mK | ||
Melting Point +165°C | ||
Water Absorption 0.5% | ||
Elongation 30% | ||
- COO (Country of Origin):
- DE
Acetal Copolymer
Low moisture absorption and good chemical resistance with excellent mechanical strength. Dimensionally stable, suitable for close tolerance components, bearings, bushes, gears, valves and valve seatings. White in colour
Standards
DIN 50 014
Acetal Copolymer & Homopolymer
