Harting Har-Flexicon 2-pin PCB Terminal Block, 2.54mm Pitch, Rows, Screw Termination
- RS Stock No.:
- 122-9780
- Mfr. Part No.:
- 14010213110160
- Brand:
- HARTING
View all PCB Terminal Blocks
Available to back order for despatch 28/12/2023
Price Each
£1.32
(exc. VAT)
£1.58
(inc. VAT)
| Units | Per unit |
| 1 + | £1.32 |
Packaging Options:
- RS Stock No.:
- 122-9780
- Mfr. Part No.:
- 14010213110160
- Brand:
- HARTING
- COO (Country of Origin):
- CN
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Harting har-flexicon® 2.54mm PCB Terminal Blocks
Brought to you by Harting, these har-flexicon® 2.54mm mini I/O PCB SMT pluggable terminal blocks are for the rapid termination of single wires. These har-flexicon® pluggable terminal blocks have push-in spring-cage terminals that accept a wire size of 24 to 20 AWG. The terminal blocks also feature tin plated 6A contacts, and are available with a vertical or horizontal orientation. har-flexicon® PCB SMT pluggable terminal blocks are ideally suited for providing a link between the periphery and printed circuit boards in industrial devices.
2.54mm Pitch Harting PCB Terminal Blocks
Specifications
| Attribute | Value |
| Number of Contacts | 2 |
| Pitch | 2.54mm |
| Number of Rows | 1 |
| Mounting Type | Through Hole |
| Gender | Female |
| Termination Method | Screw |
| Type | Spring Cage |
| Current Rating | 6A |
| Body Orientation | Horizontal |
| Colour | White |
| Voltage Rating | 160 V |
| Series | Har-Flexicon |
| Depth | 5mm |
| Length | 9.77mm |
| Width | 9.2mm |
| Material | Liquid Crystal Polymer (Insulation) |
