Phoenix Contact PCB Terminal Block, 3-Contact, 5 mm Pitch, Wave Soldering Mount, 1 Row
- RS Stock No.:
- 608-142
- Mfr. Part No.:
- 1823421
- Brand:
- Phoenix Contact
Subtotal (1 pack of 180 units)*
£369.70
(exc. VAT)
£443.64
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 03 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £369.70 | £2.054 |
*price indicative
- RS Stock No.:
- 608-142
- Mfr. Part No.:
- 1823421
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 3 | |
| Pitch | 5mm | |
| Number of Rows | 1 | |
| Current | 17.5A | |
| Housing Material | Liquid Crystal Polymer | |
| Mount Type | Wave Soldering Mount | |
| Minimum Wire Size mm² | 0.2mm² | |
| Maximum Wire Size mm² | 1.5mm² | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 16AWG | |
| Orientation | 90° | |
| Colour | Black | |
| Wire Connection Method | Push-in Spring | |
| Voltage | 32V | |
| Standards/Approvals | IEC 60998-2-2:2002-12, IEC 60998-1:2002-12, VDE, IEC 60947-7-4:2013-08, IEC 60947-7-4:2019-01, DIN EN 61340-5-1 (VDE 0300-5-1): 2008-07, cULus Recognised | |
| Width | 14mm | |
| Length | 7.7mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Terminal Block | ||
Number of Contacts 3 | ||
Pitch 5mm | ||
Number of Rows 1 | ||
Current 17.5A | ||
Housing Material Liquid Crystal Polymer | ||
Mount Type Wave Soldering Mount | ||
Minimum Wire Size mm² 0.2mm² | ||
Maximum Wire Size mm² 1.5mm² | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 16AWG | ||
Orientation 90° | ||
Colour Black | ||
Wire Connection Method Push-in Spring | ||
Voltage 32V | ||
Standards/Approvals IEC 60998-2-2:2002-12, IEC 60998-1:2002-12, VDE, IEC 60947-7-4:2013-08, IEC 60947-7-4:2019-01, DIN EN 61340-5-1 (VDE 0300-5-1): 2008-07, cULus Recognised | ||
Width 14mm | ||
Length 7.7mm | ||
- COO (Country of Origin):
- PL
The Phoenix Contact Printed circuit board terminal block designed for efficient electrical connections in compact spaces. Engineered for a nominal current of 17.5 A at a rated voltage of 320 V, this terminal block seamlessly integrates into THR soldering and wave soldering processes. Its innovative push-in spring connection method simplifies installation, eliminating the need for additional tools while ensuring a stable and secure contact. The product is particularly suited for applications requiring robust performance in demanding environments, showcasing resilience with moisture sensitivity and compliance with WEEE/RoHS standards.
Compatible with reflow and wave soldering processes for versatile usage
Defined contact force maintains stable electrical connections over time
Integrated testing options enhance quick troubleshooting in circuit applications
Made with high quality materials to ensure reliability in industrial settings
