Phoenix Contact ZFKKDSA 1 Series PCB Terminal Block, 8-Contact, 5.08 mm Pitch, Wave Soldering Mount, 2 Row
- RS Stock No.:
- 521-410
- Mfr. Part No.:
- 1891027
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£133.84
(exc. VAT)
£160.61
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 09 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £133.84 | £2.677 |
*price indicative
- RS Stock No.:
- 521-410
- Mfr. Part No.:
- 1891027
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 8 | |
| Pitch | 5.08mm | |
| Current | 12A | |
| Number of Rows | 2 | |
| Minimum Wire Size mm² | 0.2mm² | |
| Housing Material | Polyamide | |
| Mount Type | Wave Soldering Mount | |
| Maximum Wire Size mm² | 2.5mm² | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 14AWG | |
| Orientation | 45° | |
| Colour | Green | |
| Wire Connection Method | Spring Cage | |
| Voltage | 40V | |
| Standards/Approvals | CSA, cULus Recognised | |
| Width | 21.32mm | |
| Series | ZFKKDSA 1 | |
| Length | 24mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Terminal Block | ||
Number of Contacts 8 | ||
Pitch 5.08mm | ||
Current 12A | ||
Number of Rows 2 | ||
Minimum Wire Size mm² 0.2mm² | ||
Housing Material Polyamide | ||
Mount Type Wave Soldering Mount | ||
Maximum Wire Size mm² 2.5mm² | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 14AWG | ||
Orientation 45° | ||
Colour Green | ||
Wire Connection Method Spring Cage | ||
Voltage 40V | ||
Standards/Approvals CSA, cULus Recognised | ||
Width 21.32mm | ||
Series ZFKKDSA 1 | ||
Length 24mm | ||
- COO (Country of Origin):
- IN
The Phoenix Contact printed circuit board terminal is designed for reliability and versatility in connecting electrical components. Specifically engineered in the ZFKKDS(A) 1.5 series, it boasts a robust construction combining a spring-cage connection for secure fastening with a compact design to maximise space utilisation. The terminal block accommodates a nominal current of 12 A and a rated voltage of 400 V, ensuring it meets demanding electrical applications. With its dual-row configuration and multiple potential connections, this terminal block is perfect for diverse circuit designs. Its thoughtful features, including an easy-access conductor connection, simplify installation, making it an excellent choice for efficient, long-term performance in both commercial and industrial settings. The terminal is compliant with WEEE/RoHS standards, emphasising sustainability alongside functionality.
Defined contact force ensures stable long-term connectivity
Convenient conductor connection facilitated by a fixed screwdriver
Multi-level conductor connection increases contact density
Side latching system allows for flexible positioning configurations
WEEE/RoHS compliant, contributing to environmental sustainability
Available in a green housing for easy identification and aesthetic integration
Built for wave soldering, simplifying the manufacturing process
A lightweight design enables easy handling and installation
