Phoenix Contact DFMC Series PCB Terminal Block, 4-Contact, 2.54 mm Pitch, Push-in, 2 Row Socket
- RS Stock No.:
- 520-061
- Mfr. Part No.:
- 1715736
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£260.94
(exc. VAT)
£313.13
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £260.94 | £5.219 |
*price indicative
- RS Stock No.:
- 520-061
- Mfr. Part No.:
- 1715736
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 4 | |
| Pitch | 2.54mm | |
| Number of Rows | 2 | |
| Current | 6A | |
| Mount Type | Push-in | |
| Housing Material | Liquid Crystal Polymer | |
| Connector Gender | Female | |
| Colour | Black | |
| Termination Type | Socket | |
| Voltage | 160V | |
| Width | 12.66mm | |
| Standards/Approvals | IEC 60068-2-82/JEDEC JESD 201, UL 94 V0, IEC 60112, IEC 61984, IEC 60999-1:1999-11, IEC 60512-13-2:2006-02, IEC 60512-13-5:2006-02, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, DIN 50018:2013-05, IEC 60512-5-1:2002-02, IEC 60512-3-1:2002-02, IEC 60664-1:2007-04, cULus Recognised (ID: E60425-19920306), VDE report (ID: 40042389), EU RoHS, CHINA RoHS | |
| Series | DFMC | |
| Depth | 10.5mm | |
| Length | 14.4mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Terminal Block | ||
Number of Contacts 4 | ||
Pitch 2.54mm | ||
Number of Rows 2 | ||
Current 6A | ||
Mount Type Push-in | ||
Housing Material Liquid Crystal Polymer | ||
Connector Gender Female | ||
Colour Black | ||
Termination Type Socket | ||
Voltage 160V | ||
Width 12.66mm | ||
Standards/Approvals IEC 60068-2-82/JEDEC JESD 201, UL 94 V0, IEC 60112, IEC 61984, IEC 60999-1:1999-11, IEC 60512-13-2:2006-02, IEC 60512-13-5:2006-02, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, DIN 50018:2013-05, IEC 60512-5-1:2002-02, IEC 60512-3-1:2002-02, IEC 60664-1:2007-04, cULus Recognised (ID: E60425-19920306), VDE report (ID: 40042389), EU RoHS, CHINA RoHS | ||
Series DFMC | ||
Depth 10.5mm | ||
Length 14.4mm | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB connector from the COMBICON Connectors XS product line features a COMBICON DFMC 0.5 plug-in system with snap-in locking for secure connections. It uses a latching flange mounting method for stability. The contacts are made of Cu alloy for reliable conductivity, and the insulating material is LCP (liquid crystal polymer), ensuring durability and high-performance insulation.
Time saving push in connection
Defined contact force ensures that contact remains stable over the long term
Intuitive operation due to colour coded actuating push button
Optimized for tight installation situations
