TE Connectivity Buchanan Series PCB Terminal Block, 2-Contact, 3.5 mm Pitch, Board, 1 Row
- RS Stock No.:
- 476-762
- Distrelec Article No.:
- 304-51-866
- Mfr. Part No.:
- 284414-2
- Brand:
- TE Connectivity
Subtotal (1 box of 300 units)*
£183.34
(exc. VAT)
£220.01
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 27 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £183.34 | £0.611 |
*price indicative
- RS Stock No.:
- 476-762
- Distrelec Article No.:
- 304-51-866
- Mfr. Part No.:
- 284414-2
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Number of Contacts | 2 | |
| Product Type | PCB Terminal Block | |
| Pitch | 3.5mm | |
| Number of Rows | 1 | |
| Current | 12A | |
| Housing Material | Polyamide 66 | |
| Minimum Wire Size mm² | 0.05mm² | |
| Mount Type | Board | |
| Maximum Wire Size mm² | 3mm² | |
| Minimum Wire Size AWG | 30 AWG | |
| Maximum Wire Size AWG | 12 AWG | |
| Orientation | Right Angle | |
| Colour | Green | |
| Wire Connection Method | Solder | |
| Voltage | 30 V | |
| Standards/Approvals | UL | |
| Series | Buchanan | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Number of Contacts 2 | ||
Product Type PCB Terminal Block | ||
Pitch 3.5mm | ||
Number of Rows 1 | ||
Current 12A | ||
Housing Material Polyamide 66 | ||
Minimum Wire Size mm² 0.05mm² | ||
Mount Type Board | ||
Maximum Wire Size mm² 3mm² | ||
Minimum Wire Size AWG 30 AWG | ||
Maximum Wire Size AWG 12 AWG | ||
Orientation Right Angle | ||
Colour Green | ||
Wire Connection Method Solder | ||
Voltage 30 V | ||
Standards/Approvals UL | ||
Series Buchanan | ||
- COO (Country of Origin):
- IT
The TE Connectivity 2 Position PCB Terminal Block is designed for enhanced connectivity in wire-to-board applications, ensuring robust electrical performance and reliability. Its compact structure accommodates a 3.5 mm centreline pitch, making it ideal for space-constrained environments. The right angle orientation with a 90° wire entry angle allows for easy integration into various circuit designs. Engineered to support wire sizes from 30 to 12 AWG, this terminal block meets stringent operational standards, including a maximum operating voltage of 300 VAC. With features that include side stackability, this product stands out in versatility for diverse electronic applications. The use of air-tight materials enhances durability, making the terminal block suitable for a wide range of temperatures, from -40 to 110 °C. Its compliance with various regulations underscores the commitment to quality and safety, making it a reliable choice for engineers and manufacturers alike.
Designed to accommodate high performance wire to board connections
Compact design ideal for space limited electronic assemblies
Constructed to endure a wide operating temperature range
Boasts side stackable configuration for flexible designs
Robust terminal block structure ensures reliable electrical signals
Suitable for a variety of wire sizes to accommodate diverse applications
Crafted from durable materials for long lasting service life
