Samtec TSW Series Right Angle Pin Header, 100 Contact(s), 2.54mm Pitch, 2 Row(s), Unshrouded
- RS Stock No.:
- 226-3586
- Mfr. Part No.:
- TSW-150-08-S-D-RA
- Brand:
- Samtec
Available to back order for despatch when stock is available
Price Each
£6.55
(exc. VAT)
£7.86
(inc. VAT)
Units | Per unit |
|---|---|
| 1 - 9 | £6.55 |
| 10 - 99 | £6.11 |
| 100 - 199 | £5.75 |
| 200 + | £5.51 |
- RS Stock No.:
- 226-3586
- Mfr. Part No.:
- TSW-150-08-S-D-RA
- Brand:
- Samtec
Technical Reference
Legislation and Compliance
Product Details
The Samtec through hole sq post header standard strip has PBT insulation. Terminal is made up of phosphor bronze.
Voltage Rating up to 550 VAC mated with SSW
It is RoHS Compliant
It is RoHS Compliant
Specifications
Attribute | Value |
|---|---|
| Series | TSW |
| Pitch | 2.54mm |
| Number of Contacts | 100 |
| Number of Rows | 2 |
| Body Orientation | Right Angle |
| Shrouded/Unshrouded | Unshrouded |
