Samtec TSW Series Right Angle Pin Header, 150 Contact(s), 2.54mm Pitch, 3 Row(s), Unshrouded

RS Stock No.:: 226-3583
Mfr. Part No.:: TSW-150-08-L-T-RA
Brand:: Samtec

Samtec TSW Series Right Angle Pin Header, 150 Contact(s), 2.54mm Pitch, 3 Row(s), Unshrouded

Available to back order for despatch 12/06/2024

Added

Price Each

£6.76

(exc. VAT)

£8.11

(inc. VAT)

Units	Per unit
1 - 9	£6.76
10 - 99	£6.48
100 - 199	£5.98
200 +	£5.66

RS Stock No.:: 226-3583
Mfr. Part No.:: TSW-150-08-L-T-RA
Brand:: Samtec

Technical Reference

Datasheet - TSW-150-08-L-T-RA

Legislation and Compliance

Product Details

The Samtec through hole sq post header standard strip has PBT insulation. Terminal is made up of phosphor bronze.

Voltage Rating up to 550 VAC mated with SSW
It is RoHS Compliant

Specifications

Attribute	Value
Series	TSW
Pitch	2.54mm
Number of Contacts	150
Number of Rows	3
Body Orientation	Right Angle
Shrouded/Unshrouded	Unshrouded
