Samtec HTSW Series Straight Through Hole Pin Header, 3 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 180-2090
- Mfr. Part No.:
- HTSW-103-07-F-S
- Brand:
- Samtec
Save 38% when you buy 5000 units
Subtotal (1 pack of 10 units)*
£2.99
(exc. VAT)
£3.59
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 999,999,990 unit(s) shipping from 23 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
10 - 90 | £0.299 | £2.99 |
100 - 240 | £0.269 | £2.69 |
250 - 990 | £0.244 | £2.44 |
1000 - 4990 | £0.205 | £2.05 |
5000 + | £0.185 | £1.85 |
*price indicative
- RS Stock No.:
- 180-2090
- Mfr. Part No.:
- HTSW-103-07-F-S
- Brand:
- Samtec
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Samtec | |
Series | HTSW | |
Pitch | 2.54mm | |
Number of Contacts | 3 | |
Number of Rows | 1 | |
Body Orientation | Straight | |
Shrouded/Unshrouded | Unshrouded | |
Connector System | Board to Board | |
Mounting Type | Through Hole | |
Termination Method | Solder | |
Contact Plating | Gold | |
Contact Material | Phosphor Bronze | |
Current Rating | 4.3A | |
Tail Pin Length | 2.54mm | |
Mating Pin Length | 5.84mm | |
Voltage Rating | 400.0 V , 500.0 V ac, 550.0 V ac | |
Select all | ||
---|---|---|
Brand Samtec | ||
Series HTSW | ||
Pitch 2.54mm | ||
Number of Contacts 3 | ||
Number of Rows 1 | ||
Body Orientation Straight | ||
Shrouded/Unshrouded Unshrouded | ||
Connector System Board to Board | ||
Mounting Type Through Hole | ||
Termination Method Solder | ||
Contact Plating Gold | ||
Contact Material Phosphor Bronze | ||
Current Rating 4.3A | ||
Tail Pin Length 2.54mm | ||
Mating Pin Length 5.84mm | ||
Voltage Rating 400.0 V , 500.0 V ac, 550.0 V ac | ||
Contact System: .025" (0.635 mm) square post
Orientation: Vertical, right-angle
Pitch: .100" (2.54 mm)
Special Features: Suitable for most high-temperature board processing
Termination: Through-hole
Orientation: Vertical, right-angle
Pitch: .100" (2.54 mm)
Special Features: Suitable for most high-temperature board processing
Termination: Through-hole
