Samtec TSW Series Straight Through Hole Pin Header, 3 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 161-2248
- Mfr. Part No.:
- TSW-103-07-F-S
- Brand:
- Samtec
Save 24% when you buy 1790000 units
Subtotal (1 box of 3580 units)*
£501.20
(exc. VAT)
£608.60
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 22 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 3580 - 32220 | £0.14 | £501.20 |
| 35800 - 175420 | £0.115 | £411.70 |
| 179000 - 354420 | £0.112 | £400.96 |
| 358000 - 1786420 | £0.109 | £390.22 |
| 1790000 + | £0.106 | £379.48 |
*price indicative
- RS Stock No.:
- 161-2248
- Mfr. Part No.:
- TSW-103-07-F-S
- Brand:
- Samtec
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Samtec | |
| Series | TSW | |
| Pitch | 2.54mm | |
| Number of Contacts | 3 | |
| Number of Rows | 1 | |
| Body Orientation | Straight | |
| Shrouded/Unshrouded | Unshrouded | |
| Connector System | Board to Board, Wire to Board | |
| Mounting Type | Through Hole | |
| Termination Method | Solder | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold | |
| Current Rating | 4.7A | |
| Voltage Rating | 465.0 V | |
Select all | ||
|---|---|---|
Brand Samtec | ||
Series TSW | ||
Pitch 2.54mm | ||
Number of Contacts 3 | ||
Number of Rows 1 | ||
Body Orientation Straight | ||
Shrouded/Unshrouded Unshrouded | ||
Connector System Board to Board, Wire to Board | ||
Mounting Type Through Hole | ||
Termination Method Solder | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold | ||
Current Rating 4.7A | ||
Voltage Rating 465.0 V | ||
