TE Connectivity AMPMODU Series Right Angle Through Hole PCB Header, 10 Contact(s), 2 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 526-370
- Distrelec Article No.:
- 304-53-469
- Mfr. Part No.:
- 1-2842115-0
- Brand:
- TE Connectivity
Subtotal (1 tube of 116 units)*
£195.79
(exc. VAT)
£234.95
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 08 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 + | £195.79 | £1.688 |
*price indicative
- RS Stock No.:
- 526-370
- Distrelec Article No.:
- 304-53-469
- Mfr. Part No.:
- 1-2842115-0
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | AMPMODU | |
| Product Type | PCB Header | |
| Current | 2A | |
| Pitch | 2mm | |
| Housing Material | Polyamide Fibreglass | |
| Number of Contacts | 10 | |
| Number of Rows | 1 | |
| Orientation | Right Angle | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Connector System | Board-to-Board | |
| Contact Material | Brass | |
| Contact Plating | Gold | |
| Minimum Operating Temperature | -40°C | |
| Termination Type | Solder | |
| Row Pitch | 2mm | |
| Maximum Operating Temperature | 125°C | |
| Tail Pin Length | 2.8mm | |
| Standards/Approvals | China RoHS 2 Compliant, EU ELV Compliant, EU RoHS Compliant, REACH Compliant, UL 94V-0, UL E28476, UL Recognised | |
| Mating Pin Length | 4mm | |
| Voltage | 125V | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series AMPMODU | ||
Product Type PCB Header | ||
Current 2A | ||
Pitch 2mm | ||
Housing Material Polyamide Fibreglass | ||
Number of Contacts 10 | ||
Number of Rows 1 | ||
Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Connector System Board-to-Board | ||
Contact Material Brass | ||
Contact Plating Gold | ||
Minimum Operating Temperature -40°C | ||
Termination Type Solder | ||
Row Pitch 2mm | ||
Maximum Operating Temperature 125°C | ||
Tail Pin Length 2.8mm | ||
Standards/Approvals China RoHS 2 Compliant, EU ELV Compliant, EU RoHS Compliant, REACH Compliant, UL 94V-0, UL E28476, UL Recognised | ||
Mating Pin Length 4mm | ||
Voltage 125V | ||
- COO (Country of Origin):
- CN
The TE Connectivity PCB Mount Header is designed to facilitate reliable connections in demanding applications. Its right-angle configuration and board-to-board system make it ideal for tight spaces, ensuring seamless integration into various electronic assemblies. Featuring ten positions with a 2 mm centreline, this connector supports a wide range of PCB thicknesses. The breakaway design enhances versatility in assembly processes, allowing for easy placement and secure retention. Crafted with high-quality materials, including a thermoplastic housing and nickel-plated contacts, this component ensures durability and excellent performance. Its compatibility with industry standards guarantees reliability and safety across applications, while the superior soldering capability offers additional ease during installation, making it a perfect choice for both prototyping and production phases.
Right-angle orientation optimises space utilisation
Ten positions provide extensive connectivity options
Breakaway profile allows for adaptable configurations
Durable thermoplastic housing ensures long-lasting performance
Nickel-plated contacts enhance conductivity and reliability
Compatible with industry standards for assured safety
Designed for easy placement during assembly processes
High operating voltage supports demanding applications
Soldering capability ensures a secure and dependable connection
Compact design integrates seamlessly into electronic products
