Phoenix Contact DMCV Series Straight Wave Soldering Mount PCB Header, 34 Contact(s), 3.5 mm Pitch, 2 Row, Shrouded

RS Stock No.:: 521-398
Mfr. Part No.:: 1874881
Brand:: Phoenix Contact

Phoenix Contact DMCV Series Straight Wave Soldering Mount PCB Header, 34 Contact(s), 3.5 mm Pitch, 2 Row, Shrouded

Subtotal (1 pack of 50 units)*

£358.70

(exc. VAT)

£430.44

(inc. VAT)

Stock information currently inaccessible - Please check back later

Pack(s)	Per Pack	Per unit*
1 +	£358.70	£7.174

*price indicative

RS Stock No.:: 521-398
Mfr. Part No.:: 1874881
Brand:: Phoenix Contact

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Phoenix Contact
	Series	DMCV
	Product Type	PCB Header
	Current	8A
	Pitch	3.5mm
	Housing Material	Liquid Crystal Polymer
	Number of Contacts	34
	Number of Rows	2
	Orientation	Straight
	Shrouded/Unshrouded	Shrouded
	Mount Type	Wave Soldering Mount
	Connector System	COMBICON DFMC 1
	Contact Material	Copper Alloy
	Contact Plating	Nickel, Tin
	Row Pitch	3.5mm
	Termination Type	Solder
	Minimum Operating Temperature	-40°C
	Contact Gender	Male
	Maximum Operating Temperature	100°C
	Tail Pin Length	2.6mm
	Mating Pin Length	2.6mm
	Standards/Approvals	cULus Recognised, VDE report
	Voltage	160 V

	Select all
	Brand Phoenix Contact
	Series DMCV
	Product Type PCB Header
	Current 8A
	Pitch 3.5mm
	Housing Material Liquid Crystal Polymer
	Number of Contacts 34
	Number of Rows 2
	Orientation Straight
	Shrouded/Unshrouded Shrouded
	Mount Type Wave Soldering Mount
	Connector System COMBICON DFMC 1
	Contact Material Copper Alloy
	Contact Plating Nickel, Tin
	Row Pitch 3.5mm
	Termination Type Solder
	Minimum Operating Temperature -40°C
	Contact Gender Male
	Maximum Operating Temperature 100°C
	Tail Pin Length 2.6mm
	Mating Pin Length 2.6mm
	Standards/Approvals cULus Recognised, VDE report
	Voltage 160 V

Datasheet - 1874881

COO (Country of Origin):: DE

The Phoenix Contact PCB header is designed to meet the demands of modern electronic applications where reliability and performance are crucial. Built with a focus on integration into SMT soldering processes, it ensures a robust connection for multi-row arrangements on printed circuit boards. Its compact design accommodates tight spaces without compromising functionality, showcasing a high level of engineering tailored for efficiency. The product is ideal for various applications that require stable electrical connections, offering versatility and ease of installation. With features that cater to both performance and convenience, this header stands out in the realm of PCB components, ensuring your devices connect seamlessly and reliably.

Designed for easy integration into PCB layouts

Facilitates versatile multi-row configurations

Compact size optimises space usage on PCBs

Capable of withstanding high thermal and mechanical loads

Durable construction ensures long service life

Compliant with stringent environmental regulations

Guarantees excellent electrical contact performance

Supports straightforward wave and reflow soldering processes

Manufactured with WEEE/RoHS compliance in mind

Phoenix Contact DMCV Series Straight Wave Soldering Mount PCB Header, 34 Contact(s), 3.5 mm Pitch, 2 Row, Shrouded
