Phoenix Contact DMCV Series Wave Soldering Mount PCB Header, 10 Contact(s), 3.5 mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 556-274
- Mfr. Part No.:
- 1053841
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£187.36
(exc. VAT)
£224.83
(inc. VAT)
Stock information currently inaccessible
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £187.36 | £3.747 |
*price indicative
- RS Stock No.:
- 556-274
- Mfr. Part No.:
- 1053841
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Header | |
| Series | DMCV | |
| Current | 8A | |
| Pitch | 3.5mm | |
| Number of Contacts | 10 | |
| Housing Material | Polybutylene Terephthalate | |
| Number of Rows | 2 | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Wave Soldering Mount | |
| Connector System | COMBICON DFMC 1 | |
| Contact Plating | Tin Plated | |
| Contact Material | Copper Alloy | |
| Minimum Operating Temperature | -40°C | |
| Termination Type | Solder | |
| Row Pitch | 3.5mm | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 100°C | |
| Tail Pin Length | 3.5mm | |
| Standards/Approvals | cULus Recognised, IEC 60068-2-70, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-5-1, IEC 60664-1, ISO 6988 | |
| Mating Pin Length | 3.5mm | |
| Voltage | 160 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Header | ||
Series DMCV | ||
Current 8A | ||
Pitch 3.5mm | ||
Number of Contacts 10 | ||
Housing Material Polybutylene Terephthalate | ||
Number of Rows 2 | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Wave Soldering Mount | ||
Connector System COMBICON DFMC 1 | ||
Contact Plating Tin Plated | ||
Contact Material Copper Alloy | ||
Minimum Operating Temperature -40°C | ||
Termination Type Solder | ||
Row Pitch 3.5mm | ||
Contact Gender Male | ||
Maximum Operating Temperature 100°C | ||
Tail Pin Length 3.5mm | ||
Standards/Approvals cULus Recognised, IEC 60068-2-70, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-5-1, IEC 60664-1, ISO 6988 | ||
Mating Pin Length 3.5mm | ||
Voltage 160 V | ||
- COO (Country of Origin):
- CN
The Phoenix Contact PCB header designed to optimise space and enhance connectivity in various applications. Built with a pitch of 3.5 mm, this component offers a compact yet effective solution for a range of electrical connections. With its robust design, it supports a nominal current of 8 A and a rated voltage of 160 V, ensuring reliable performance across demanding environments. The header features a linear pin layout with 5 positions and 10 connections, making it ideal for multi-row arrangements on PCBs. Conforming to contemporary standards, this product ensures safety and compliance with regulations, making it suitable for various uses in electronic systems. Whether for industrial or commercial applications, this PCB header stands out with its practical design and excellent mounting capabilities, ensuring adaptability to different PCB setups.
Conductor connection on multiple levels provides increased contact density
Compact size fits seamlessly into space-constrained applications
Vertical connection enables efficient multi-row PCB arrangements
Familiar mounting principles support global usability
WEEE/RoHS-compliant materials ensure environmental sustainability
Tin-plated contact material enhances durability and conductivity
Tested for mechanical robustness, ensuring high reliability in various conditions
Wide operational temperature range accommodates diverse environmental conditions
Cardboard packaging ensures safe and eco-friendly conservation during transport
