Phoenix Contact DMCV Series Straight Through Hole PCB Header, 38 Contact(s), 3.5 mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 489-158
- Mfr. Part No.:
- 1787373
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£718.33
(exc. VAT)
£862.00
(inc. VAT)
Stock information currently inaccessible
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £718.33 | £14.367 |
*price indicative
- RS Stock No.:
- 489-158
- Mfr. Part No.:
- 1787373
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Header | |
| Series | DMCV | |
| Current | 8A | |
| Pitch | 3.5mm | |
| Number of Contacts | 38 | |
| Housing Material | Liquid Crystal Polymer | |
| Number of Rows | 2 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Connector System | COMBICON DFMC 1 | |
| Contact Material | Copper Alloy | |
| Contact Plating | Tin Plated | |
| Row Pitch | 3.5mm | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -40°C | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 100°C | |
| Tail Pin Length | 2mm | |
| Standards/Approvals | cULus Recognised, VDE | |
| Mating Pin Length | 2mm | |
| Voltage | 160 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Header | ||
Series DMCV | ||
Current 8A | ||
Pitch 3.5mm | ||
Number of Contacts 38 | ||
Housing Material Liquid Crystal Polymer | ||
Number of Rows 2 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Connector System COMBICON DFMC 1 | ||
Contact Material Copper Alloy | ||
Contact Plating Tin Plated | ||
Row Pitch 3.5mm | ||
Termination Type Solder | ||
Minimum Operating Temperature -40°C | ||
Contact Gender Male | ||
Maximum Operating Temperature 100°C | ||
Tail Pin Length 2mm | ||
Standards/Approvals cULus Recognised, VDE | ||
Mating Pin Length 2mm | ||
Voltage 160 V | ||
- COO (Country of Origin):
- DE
The Phoenix Contact PCB header offers a reliable solution for connecting various electronic components, designed specifically for integration into the SMT soldering process. The compact form factor allows for multi-row arrangement, optimising space on the PCB for those critical applications. The robust construction ensures durability, with features tailored to meet the demands of modern electronic design. This header stands out for its black insulating material and is compliant with WEEE/RoHS standards, assuring users of its environmentally friendly credentials. With a nominal current rating of 8 A and a rated voltage of 160 V, this product combines efficiency with safety, making it a versatile addition to any electronic assembly.
Vertically oriented connections facilitate efficient multi-row PCB layout
Compact design caters to space-constrained applications
Sn-plated contacts ensure optimal conductivity and corrosion resistance
Solder pins designed for ease of mounting and enhanced reliability
Durable construction withstands harsh operating conditions
Moisture Sensitivity Level 1 aids in production planning
VDE and cULus approvals guarantee adherence to international safety standards
Designed for seamless integration into the prevailing production processes
