Phoenix Contact DMCV Series Straight Through Hole PCB Header, 16 Contact(s), 3.5 mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 483-785
- Mfr. Part No.:
- 1874205
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£373.28
(exc. VAT)
£447.94
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 13 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £373.28 | £7.466 |
*price indicative
- RS Stock No.:
- 483-785
- Mfr. Part No.:
- 1874205
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Series | DMCV | |
| Product Type | PCB Header | |
| Pitch | 3.5mm | |
| Current | 8A | |
| Number of Contacts | 16 | |
| Housing Material | Liquid Crystal Polymer | |
| Number of Rows | 2 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | COMBICON DFMC 1 | |
| Mount Type | Through Hole | |
| Contact Material | Copper Alloy | |
| Contact Plating | Tin Plated | |
| Minimum Operating Temperature | -40°C | |
| Row Pitch | 3.5mm | |
| Termination Type | Solder | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 100°C | |
| Tail Pin Length | 2.6mm | |
| Standards/Approvals | cULus Recognised, VDE report | |
| Mating Pin Length | 2.6mm | |
| Voltage | 160 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Series DMCV | ||
Product Type PCB Header | ||
Pitch 3.5mm | ||
Current 8A | ||
Number of Contacts 16 | ||
Housing Material Liquid Crystal Polymer | ||
Number of Rows 2 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Connector System COMBICON DFMC 1 | ||
Mount Type Through Hole | ||
Contact Material Copper Alloy | ||
Contact Plating Tin Plated | ||
Minimum Operating Temperature -40°C | ||
Row Pitch 3.5mm | ||
Termination Type Solder | ||
Contact Gender Male | ||
Maximum Operating Temperature 100°C | ||
Tail Pin Length 2.6mm | ||
Standards/Approvals cULus Recognised, VDE report | ||
Mating Pin Length 2.6mm | ||
Voltage 160 V | ||
- COO (Country of Origin):
- DE
The Phoenix Contact PCB header is designed for superior integration into various electronic applications, ensuring reliable connectivity and seamless performance. It features a robust construction suitable for high-speed soldering processes, allowing for efficient wave or THR soldering methods. The vertical connection design facilitates a multi-row assembly, significantly saving space on your PCB. With intuitive locking mechanisms and a threaded flange for stability, this component exhibits optimal durability and ease of use. Ideal for applications requiring a compact design without compromising on functionality, the product serves as an essential component in modern electronic devices.
Designed to integrate effortlessly into SMT soldering processes
Vertical connection allows for efficient multi-row arrangements
Equipped with a user-friendly Lock and Release lever for easy operation
Threaded flange enhances mechanical stability
Compact size perfect for space-sensitive applications
