Molex 502430 Series Vertical Surface PCB Header, 40 Contact(s), 0.4 mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 476-528
- Mfr. Part No.:
- 502430-4010
- Brand:
- Molex
Subtotal (1 reel of 3000 units)*
£2,180.38
(exc. VAT)
£2,616.46
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per unit* |
|---|---|---|
| 1 + | £2,180.38 | £0.727 |
*price indicative
- RS Stock No.:
- 476-528
- Mfr. Part No.:
- 502430-4010
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Series | 502430 | |
| Product Type | PCB Header | |
| Current | 0.3A | |
| Pitch | 0.4mm | |
| Number of Contacts | 40 | |
| Number of Rows | 2 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Surface | |
| Contact Plating | Gold | |
| Contact Material | Phosphor Bronze | |
| Termination Type | Surface Mount | |
| Row Pitch | 0.4mm | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | REACH, RoHS | |
| Voltage | 50 Vrms | |
| Distrelec Product Id | 304-56-459 | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Series 502430 | ||
Product Type PCB Header | ||
Current 0.3A | ||
Pitch 0.4mm | ||
Number of Contacts 40 | ||
Number of Rows 2 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Surface | ||
Contact Plating Gold | ||
Contact Material Phosphor Bronze | ||
Termination Type Surface Mount | ||
Row Pitch 0.4mm | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals REACH, RoHS | ||
Voltage 50 Vrms | ||
Distrelec Product Id 304-56-459 | ||
- COO (Country of Origin):
- JP
The TE Connectivity 0.40mm Pitch Board-to-Board Connector is designed to provide superior connectivity solutions where space is at a premium. With its dual-row configuration and a stacking height of just 1.00mm, this connector seamlessly integrates into various board layouts. Ideal for applications requiring efficient signal transmission, it supports up to 40 circuits while maintaining robust performance standards. The connector is manufactured using high-quality materials, ensuring durability and reliability even in demanding environments. With a surface mount termination interface, it simplifies PCB assembly and optimises layout flexibility. This connector is well-suited for both industrial and consumer electronics, making it a versatile choice for a variety of applications.
Designed for optimal space utilisation in compact designs
High circuit density ensures reliable signal integrity
Tailored for board-to-board connectivity applications
Supports a wide operating temperature range for versatility
Manufactured with halogen-free materials for environmental compliance
Surface mount style enhances PCB soldering efficiency
Orientated vertically for simplified layout and installation
Mated height of 1.00mm minimises overall footprint
Features gold plating to ensure superior conductivity
Offers a maximum current rating of 0.3A per contact
