TE Connectivity AMPMODU Series Vertical Board PCB Header, 34 Contact(s), 2.54 mm Pitch, 2 Row
- RS Stock No.:
- 471-016
- Mfr. Part No.:
- 1-147747-7
- Brand:
- TE Connectivity
Subtotal (1 reel of 250 units)*
£1,193.42
(exc. VAT)
£1,432.10
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 02 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per unit* |
|---|---|---|
| 1 + | £1,193.42 | £4.774 |
*price indicative
- RS Stock No.:
- 471-016
- Mfr. Part No.:
- 1-147747-7
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | AMPMODU | |
| Product Type | PCB Header | |
| Current | 3A | |
| Pitch | 2.54mm | |
| Number of Contacts | 34 | |
| Housing Material | Glass Filled Polyester | |
| Number of Rows | 2 | |
| Orientation | Vertical | |
| Mount Type | Board | |
| Connector System | Board-to-Board | |
| Contact Plating | Gold | |
| Contact Material | Phosphor Bronze | |
| Termination Type | Surface Mount | |
| Minimum Operating Temperature | 65°C | |
| Row Pitch | 2.54mm | |
| Contact Gender | Female | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | CSA LR7189, UL 94V-0, UL E28476 | |
| Voltage | 250 V | |
| Distrelec Product Id | 304-53-375 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series AMPMODU | ||
Product Type PCB Header | ||
Current 3A | ||
Pitch 2.54mm | ||
Number of Contacts 34 | ||
Housing Material Glass Filled Polyester | ||
Number of Rows 2 | ||
Orientation Vertical | ||
Mount Type Board | ||
Connector System Board-to-Board | ||
Contact Plating Gold | ||
Contact Material Phosphor Bronze | ||
Termination Type Surface Mount | ||
Minimum Operating Temperature 65°C | ||
Row Pitch 2.54mm | ||
Contact Gender Female | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals CSA LR7189, UL 94V-0, UL E28476 | ||
Voltage 250 V | ||
Distrelec Product Id 304-53-375 | ||
- COO (Country of Origin):
- TW
The TE Connectivity PCB Mount Receptacle is engineered for seamless integration in board-to-board applications, optimizing connectivity with its 34-position design. Its vertical orientation and surface mount capabilities ensure a robust connection, making it the ideal choice for modern electronic assembly. With a centerline of 2.54 mm, this connector supports various industry standards, facilitating reliable performance within a wide range of environments. Manufactured using high-quality materials, it promises durability and excellent signal integrity, whilst its black housing enhances aesthetics and corrosion resistance. Designed specifically for high-temperature operations, this receptacle is suitable for demanding applications, ensuring your projects maintain functionality under extreme conditions.
Enhanced signal integrity for high-performance applications
Robust design that withstands challenging environmental conditions
Flexible mounting options ensure compatibility with various PCB layouts
Efficient heat dissipation through an effective housing design
Manufactured with gold plating for superior conductivity
Meets industry standards for safety and performance
Environmentally compliant, addressing various regulatory standards
