WAGO 734 Series Angled Through Hole Header, 10 Contact(s), 3.5 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 222-412
- Mfr. Part No.:
- 734-170/108-000
- Brand:
- WAGO
Subtotal (1 box of 100 units)*
£356.53
(exc. VAT)
£427.84
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 09 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £356.53 | £3.565 |
*price indicative
- RS Stock No.:
- 222-412
- Mfr. Part No.:
- 734-170/108-000
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | Header | |
| Series | 734 | |
| Current | 10A | |
| Pitch | 3.5mm | |
| Housing Material | Polyamide 66 | |
| Number of Contacts | 10 | |
| Number of Rows | 1 | |
| Orientation | Angled | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | MCS | |
| Mount Type | Through Hole | |
| Contact Plating | Tin | |
| Contact Material | Electrolytic Copper | |
| Minimum Operating Temperature | 60°C | |
| Termination Type | Solder | |
| Row Pitch | 3.5mm | |
| Contact Gender | Male | |
| Tail Pin Length | 3.8mm | |
| Maximum Operating Temperature | 100°C | |
| Standards/Approvals | CSA, IEC/EN 60664-1, UL 1059 | |
| Voltage | 160 V | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type Header | ||
Series 734 | ||
Current 10A | ||
Pitch 3.5mm | ||
Housing Material Polyamide 66 | ||
Number of Contacts 10 | ||
Number of Rows 1 | ||
Orientation Angled | ||
Shrouded/Unshrouded Shrouded | ||
Connector System MCS | ||
Mount Type Through Hole | ||
Contact Plating Tin | ||
Contact Material Electrolytic Copper | ||
Minimum Operating Temperature 60°C | ||
Termination Type Solder | ||
Row Pitch 3.5mm | ||
Contact Gender Male | ||
Tail Pin Length 3.8mm | ||
Maximum Operating Temperature 100°C | ||
Standards/Approvals CSA, IEC/EN 60664-1, UL 1059 | ||
Voltage 160 V | ||
The Wago THT Male Header is a precision engineered component designed to enhance connectivity in various electronic applications. With an innovative angled design, it ensures maximum protection against mismating, allowing only compatible connectors to mate. This product features a robust 10 pole configuration, with 3.5 mm pin spacing, ideal for efficient board to board connections. The overall construction includes high quality materials, ensuring durability and reliability, complemented by a light grey finish that blends seamlessly into various PCB designs.
Offers both horizontal and vertical mounting options
Constructed with a durable polyamide housing
Light grey colour ensures compatibility with various device aesthetics
Variable coding feature to prevent connection errors
Equipped with anti rotation protection for reliable performance
Suitable for a wide range of electrical ratings
