Testo 760-3 Handheld Digital Multimeter, True RMS, 10A ac Max, 10A dc Max, 1000V ac Max - UKAS Calibrated
- RS Stock No.:
- 905-6897
- Mfr. Part No.:
- 0590 7603
- Brand:
- Testo
Subtotal (1 unit)*
£242.20
(exc. VAT)
£290.64
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 7 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £242.20 |
*price indicative
- RS Stock No.:
- 905-6897
- Mfr. Part No.:
- 0590 7603
- Brand:
- Testo
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Testo | |
| Multimeter Type | Handheld | |
| Model Number p | 760-3 | |
| Display Type | Digital | |
| Functions Measured | AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance, Temperature | |
| Calibrated | UKAS | |
| Absolute Maximum Resistance Measurement | 60MΩ | |
| Absolute Maximum DC Current Measurement | 10A dc | |
| Absolute Maximum AC Current Measurement | 10A ac | |
| Absolute Maximum AC Voltage Measurement | 1000V ac | |
| Absolute Maximum DC Voltage Measurement | 1000V dc | |
| True RMS | Yes | |
| Absolute Maximum Capacitance Measurement | 60mF | |
| Absolute Maximum Temperature Measurement | +500°C | |
| Maximum Frequency | 30MHz | |
| Safety Category Level | CAT III, CAT IV | |
| Best DC Current Accuracy | 0.1 % | |
| Dimensions | 167 x 84 x 45mm | |
| Weight | 268g | |
| Height | 45mm | |
| Minimum Operating Temperature | -10°C | |
| Best Capacitance Measurement Accuracy | 0.1 % | |
| Maximum Operating Temperature | +50°C | |
| Length | 167mm | |
| Best AC Current Accuracy | 0.1 % | |
| Best Temperature Measurement Accuracy | 0.1 % | |
| Best DC Voltage Accuracy | 0.1 % | |
| Safety Category Voltage | 600 V, 1000V | |
| Width | 84mm | |
| Best AC Voltage Accuracy | 0.1 % | |
| Best Resistance Measurement Accuracy | 0.1 % | |
| Select all | ||
|---|---|---|
Brand Testo | ||
Multimeter Type Handheld | ||
Model Number p 760-3 | ||
Display Type Digital | ||
Functions Measured AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance, Temperature | ||
Calibrated UKAS | ||
Absolute Maximum Resistance Measurement 60MΩ | ||
Absolute Maximum DC Current Measurement 10A dc | ||
Absolute Maximum AC Current Measurement 10A ac | ||
Absolute Maximum AC Voltage Measurement 1000V ac | ||
Absolute Maximum DC Voltage Measurement 1000V dc | ||
True RMS Yes | ||
Absolute Maximum Capacitance Measurement 60mF | ||
Absolute Maximum Temperature Measurement +500°C | ||
Maximum Frequency 30MHz | ||
Safety Category Level CAT III, CAT IV | ||
Best DC Current Accuracy 0.1 % | ||
Dimensions 167 x 84 x 45mm | ||
Weight 268g | ||
Height 45mm | ||
Minimum Operating Temperature -10°C | ||
Best Capacitance Measurement Accuracy 0.1 % | ||
Maximum Operating Temperature +50°C | ||
Length 167mm | ||
Best AC Current Accuracy 0.1 % | ||
Best Temperature Measurement Accuracy 0.1 % | ||
Best DC Voltage Accuracy 0.1 % | ||
Safety Category Voltage 600 V, 1000V | ||
Width 84mm | ||
Best AC Voltage Accuracy 0.1 % | ||
Best Resistance Measurement Accuracy 0.1 % | ||
- COO (Country of Origin):
- CN
Testo 760-3 True RMS Digital Multimeter
The Testo 760-3 digital multimeter, one of three available in the range. The 760 series is designed for important electrical measuring tasks offering new function keys that replace the traditional dial which means easier operation and greater reliability. Incorrect settings are now impossible, because the measurement parameters are detected automatically via the assignment of the measuring sockets and also shown by the illumination of the appropriate function keys.
The Testo 760-3 has a larger current measurement range, the true root mean square measurement (TRMS) and a low pass filter. It also has a voltage range of up to 1000 V along with higher measuring ranges for frequency and capacitance.
The Testo 760-3 has a larger current measurement range, the true root mean square measurement (TRMS) and a low pass filter. It also has a voltage range of up to 1000 V along with higher measuring ranges for frequency and capacitance.
Features and Benefits
• Testo 760-3 TRMS digital multimeter
• Easy, modern operation with function keys instead of a dial
• Measurement parameter detection and selection via the socket assignment
• Prevents incorrect settings
• Large, backlit display
• IP64 Rated
• 0.1% accuracy
• 10A ac, 1000 V ac
• Measurement Category: CAT IV 600 V, CAT III 1000 V
• Easy, modern operation with function keys instead of a dial
• Measurement parameter detection and selection via the socket assignment
• Prevents incorrect settings
• Large, backlit display
• IP64 Rated
• 0.1% accuracy
• 10A ac, 1000 V ac
• Measurement Category: CAT IV 600 V, CAT III 1000 V
Testo 760 Digital Multimeter Options
• Testo 760-1 = RS Stock no: 905-5885 (Includes batteries and 1 set of measuring cables)
• Testo 760-2 = RS Stock no: 905-5888 (Includes batteries, 1 set of measuring cables and 1 x adapter for type K thermocouples)
• Testo 760-3 = RS Stock no: 905-5882 (Includes batteries and 1 set of measuring cables)
• Testo 760-2 = RS Stock no: 905-5888 (Includes batteries, 1 set of measuring cables and 1 x adapter for type K thermocouples)
• Testo 760-3 = RS Stock no: 905-5882 (Includes batteries and 1 set of measuring cables)
Why would you buy it?
The Testo 760-3 is the perfect tool to handle all your electrical measurement needs. The exclusive auto test-setup feature detects your lead connection and prevents switching between volts and amps to prevent damage if the leads aren’t in the proper sockets
FAQ’s
Q: Can I use this to test if a fuse is good or bad?
A: Yes, you can check a fuse functionality via a continuity test.
Q: Is this multimeter suitable for automotive use?
A: Yes, this multimeter is perfect for automotive applications and much more.
Q: Does this come with a calibration certificate?
A: RS offers calibrated options for this product and supplies all the appropriate certifications.
A: Yes, you can check a fuse functionality via a continuity test.
Q: Is this multimeter suitable for automotive use?
A: Yes, this multimeter is perfect for automotive applications and much more.
Q: Does this come with a calibration certificate?
A: RS offers calibrated options for this product and supplies all the appropriate certifications.
Standards
EN 61326-1
Approvals
TÜV, CSA & CE
Supplied with
Testo 760-3 TRMS multimeter, batteries and 1 set of measuring cables
