Keysight Technologies U3606B Bench Digital Multimeter, True RMS, 3A ac Max, 3A dc Max, 750V ac Max - RS Calibrated

RS Stock No.:: 876-3046
Mfr. Part No.:: U3606B
Brand:: Keysight Technologies

Keysight Technologies U3606B Bench Digital Multimeter, True RMS, 3A ac Max, 3A dc Max, 750V ac Max - RS Calibrated

Currently unavailable

Sorry, we don't know when this will be back in stock.

RS Stock No.:: 876-3046
Mfr. Part No.:: U3606B
Brand:: Keysight Technologies

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Keysight Technologies
	Multimeter Type	Bench
	Model Number p	U3606B
	Display Type	Digital
	Calibrated	RSCAL
	Functions Measured	AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance
	Absolute Maximum AC Voltage Measurement	750V ac
	Absolute Maximum DC Voltage Measurement	1000V dc
	Absolute Maximum DC Current Measurement	3A dc
	Absolute Maximum Resistance Measurement	100MΩ
	Absolute Maximum AC Current Measurement	3A ac
	Absolute Maximum Capacitance Measurement	10mF
	True RMS	Yes
	Maximum Frequency	100kHz
	DC Current Measurement Resolution	0.1µA dc
	DC Voltage Measurement Resolution	0.1µV dc
	Safety Category Level	CAT I, CAT II
	Capacitance Measurement Resolution	0.01nF
	Weight	3.5 (Without Rubber Bumpers) kg, 3.8 (With Rubber Bumpers) kg
	Best Resistance Measurement Accuracy	±0.25% + 0.05
	Maximum Operating Temperature	+55°C
	Safety Category Voltage	300 V, 750 V, 1000V
	Width	215 (Without Rubber Bumpers) mm, 226 (With Rubber Bumpers) mm
	Best AC Current Accuracy	±0.5% + 0.1
	Length	312 (Without Rubber Bumpers) mm, 334 (With Rubber Bumpers) mm
	Best AC Voltage Accuracy	±0.2% + 0.1
	Best Capacitance Measurement Accuracy	±1% + 0.5
	Dimensions	312 x 215 x 87 (Without Rubber Bumpers) mm, 334 x 226 x 105 (With Rubber Bumpers) mm
	Height	105 (With Rubber Bumpers) mm, 87 (Without Rubber Bumpers) mm
	Minimum Operating Temperature	0°C
	Best DC Current Accuracy	±0.15% + 0.007
	Best DC Voltage Accuracy	±0.025 %

	Select all
	Brand Keysight Technologies
	Multimeter Type Bench
	Model Number p U3606B
	Display Type Digital
	Calibrated RSCAL
	Functions Measured AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance
	Absolute Maximum AC Voltage Measurement 750V ac
	Absolute Maximum DC Voltage Measurement 1000V dc
	Absolute Maximum DC Current Measurement 3A dc
	Absolute Maximum Resistance Measurement 100MΩ
	Absolute Maximum AC Current Measurement 3A ac
	Absolute Maximum Capacitance Measurement 10mF
	True RMS Yes
	Maximum Frequency 100kHz
	DC Current Measurement Resolution 0.1µA dc
	DC Voltage Measurement Resolution 0.1µV dc
	Safety Category Level CAT I, CAT II
	Capacitance Measurement Resolution 0.01nF
	Weight 3.5 (Without Rubber Bumpers) kg, 3.8 (With Rubber Bumpers) kg
	Best Resistance Measurement Accuracy ±0.25% + 0.05
	Maximum Operating Temperature +55°C
	Safety Category Voltage 300 V, 750 V, 1000V
	Width 215 (Without Rubber Bumpers) mm, 226 (With Rubber Bumpers) mm
	Best AC Current Accuracy ±0.5% + 0.1
	Length 312 (Without Rubber Bumpers) mm, 334 (With Rubber Bumpers) mm
	Best AC Voltage Accuracy ±0.2% + 0.1
	Best Capacitance Measurement Accuracy ±1% + 0.5
	Dimensions 312 x 215 x 87 (Without Rubber Bumpers) mm, 334 x 226 x 105 (With Rubber Bumpers) mm
	Height 105 (With Rubber Bumpers) mm, 87 (Without Rubber Bumpers) mm
	Minimum Operating Temperature 0°C
	Best DC Current Accuracy ±0.15% + 0.007
	Best DC Voltage Accuracy ±0.025 %

Keysight U3606B Data Sheet

RoHS Status: Not Applicable

COO (Country of Origin):: MY

Keysight Multimeter/Power Supply U3606B

Keysight digital multimeter/power supply U3606B combines a full featured 5.5 digit digital multimeter with a 30W power supply in a single, compact unit. It is capable of powering up a DUT while the instrument user simultaneously measures voltage, current and more.

Measurement capabilities include: sweep function (ramp and scan) to simplify device characterisation for multi-level DC bias testing such as DC motor testing, transistor gain test, relay control and margin tests; low resistance measurement for higher accuracy.

Full-featured 5 digit DMM

• 5 digit, 120,000 counts resolution
• 10 measurement functions and 8 built-in math functions
• 4-wire low resistance measurement with 0.001 mΩ resolution
• 0.025% DC voltage accuracy

Full-featured 30W, DC power supply

• 30V/1 A, 100 mA/30V, 8V/3 A and 1000mV/3 A
• 0.01% + 3mV load regulation
• Over voltage (OVP) and over current (OCP) load protection
• 4.8kHz square-wave generator, auto ramp and scan capability

Other instrument features

• Built-in GPIB (IEEE-488) and USB 2.0 full speed interface
• SCPI language compatible
• Universal AC input (100V - 240V, 45Hz to 66Hz)
• Kensington lock slot to prevent theft or misplacement

Note

Accessories available separately include: rack mount kit 34190A ( 501-291 ); test leads 34133A ( 764-8696 ); current shunt 34330A ( 501-310 ); Kelvin probe set 11059A ( 692-7147 ); Kelvin clip 11062A ( 702-7914 ); PCI GPID interface card 82350B ( 694-8692 ); PCle GPIB interface card 82351A ( 694-8706 ); USB/GPIB interface card 82357B ( 716-7131 ); cable assemblies GPIB to GPIB 0.5m 10833D ( 501-102 ), 1m 10833A ( 501-099 ), 2m 10833B ( 501-089 ), 4m 10833C ( 694-8712 ), 6m 10833F ( 694-8719 ), 8m 10833G ( 694-8715 ); MSO GPIB adapter 10834A ( 694-8728 ).

Supplied with

Quick start guide, product reference CD, Keysight IO library suite, certificate of calibration, U8201A combo test lead kit, USB 2.0 high-speed Type-A to Type-B cable, AC power cord
