    Fluke 83 Handheld Digital Multimeter, True RMS, 10A ac Max, 10A dc Max, 1000V ac Max

    Fluke
    RS Stock No.:
    480-2361
    Mfr. Part No.:
    FLUKE 83V
    Brand:
    Fluke
    View all Multimeters
    20 In stock - FREE next working day delivery available
    7 available from Europe for delivery within 1 working day(s).
    Add to Basket
    Units

    Added

    Price Each

    £527.00

    (exc. VAT)

    £632.40

    (inc. VAT)

    UnitsPer unit
    1 +£527.00

    Calibration Options:

    presentation
    Calibration Type:
    RSCAL
    RS Stock No.
    481-8164

    Price Each

    £573.50

    (exc. VAT)

    £688.20

    (inc. VAT)

    presentation
    Calibration Type:
    UKAS
    RS Stock No.
    481-8170

    Price Each

    £597.50

    (exc. VAT)

    £717.00

    (inc. VAT)

    RS Stock No.:
    480-2361
    Mfr. Part No.:
    FLUKE 83V
    Brand:
    Fluke

    Legislation and Compliance

    RoHS Status: Not Applicable

    COO (Country of Origin):
    US

    Product Details

    Fluke 83V Digital Multimeter


    The Fluke 83V industrial digital multimeter is designed to help identify complex signal problems fast. The 3-3/4 digits digital multimeter features true rms readings which will give you accurate results without the complications. The 83V digital handheld multimeter features the accuracy and resolution to troubleshooting that industrial electricians around the world trust from the control room to the plant floor as well as electro -mechanical equipment in noisy, industrial, high energy environments and high altitude locations. The Fluke 83V digital multimeter also comes with a larger display screen with a bright, two level back light allowing you to view the analogue bar graphs and measurements in a dim working environment.

    Features & Benefits


    • Accurate measurements of noisy pulse-width modulated AC voltage at the VSD and the motor terminals
    • Accurate frequency measurements on VSD
    • Built-in thermometer
    • Peak Min Max mode captures intermittent as fast as 250 μs
    • Easy-to-read large digit display with bright, two-level backlight
    • CAT III 1000V, CAT IV 600V safety rated
    • Lifetime warranty

    The 83V digital multimeter measures


    AC/DC voltage & current
    Resistance
    Voltage frequency
    Diodes
    Continuity
    Capacitance
    Temperature
    Duty Cycle

    Additional specifications


    • True RMS AC voltage and current for accurate measurements on non-linear signals
    • Selectable filter for accurate voltage and frequency measurements on motor drives
    • 0.05% DC accuracy
    • 3-3/4 digit mode for precise measurements (6,000 counts)
    • Measure up to 1000 V AC and DC
    • Measure up to 10 A, 20 A for up to 30 seconds
    • Frequency to 200 kHz and % duty cycle
    • Resistance, continuity and diode test
    • 10,000 μF capacitance range for components and motor caps
    • Min/Max-Average recording with Min/Max Alert to capture variations automatically
    • Relative mode to remove test lead interference
    • Auto and manual ranging for maximum flexibility
    • Touch Hold to capture stable readings avoiding noisy signals
    • Analogue bar graph for fast changing or unstable signals
    • Input Alert provides audible warning against wrong use of input jacks

    Does it have auto turn off if left on?


    Yes - Automatic power down if left unused when switched on to preserve battery life

    Electrical safety


    All inputs are updated to the 3rd edition of ANSI/ISA S82.01 and EN61010-1 CAT IV 600 V and CAT III, 1000 V. They can withstand impulses in excess of 8.000 V and reduce risks related to surges and spikes.

    Note

    For Calibrated articles - Accuracy is specified for 1 year after calibration, at operating temperatures of 18 °C to 28 °C, with relative humidity at 0 % to 90 %

    Supplied with

    TL75 test leads, AC175 alligator clips, yellow holster, 9V battery, temperature probe, user manual, operators guide

    FLUKE Multimeter, 0.1kHz Max Frequency Resolution, 400 Hours Battery Life - 80 Series - FLUKE 83V


    Features & Benefits


    • Broad operating temperature range between -20°C and +55°C for use in challenging conditions
    • 9V alkaline battery offers 400 hours of service life for long-term use
    • Integrated fuses at the input current terminal provide short-circuit and overload protection for enhanced safety

    Applications


    • Assembly lines
    • Construction sites
    • Marine engineering

    What accessories does this multimeter come with?


    This unit comes with test probes for measuring electrical characteristics, as well as a temperature probe to assess thermal conditions on your equipment. You also get a holster and an operating manual to keep you on track for safe and proper operation.


    Specifications

    Attribute
    Value
    Multimeter TypeHandheld
    Display TypeDigital
    Functions MeasuredAC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
    True RMSYes
    Absolute Maximum AC Voltage Measurement1000V ac
    Absolute Maximum Resistance Measurement50MΩ
    Absolute Maximum DC Current Measurement10A dc
    Absolute Maximum AC Current Measurement10A ac
    Absolute Maximum DC Voltage Measurement1000V dc
    Absolute Maximum Temperature Measurement+1090°C
    Absolute Maximum Capacitance Measurement9.999F
    Maximum Frequency20kHz
    Model Number p83
    AC Current Measurement Resolution0.1µA ac
    DC Current Measurement Resolution0.1µA dc
    DC Voltage Measurement Resolution0.1mV dc
    Resistance Measurement Resolution100mΩ
    AC Voltage Measurement Resolution0.1mV ac
    Capacitance Measurement Resolution10nF
    Safety Category LevelCAT III, CAT IV
    Temperature Measurement Resolution0.1°C
    Best AC Current Accuracy±1.2% + 2 Digits
    Width86mm
    Dimensions186 x 86 x 31mm
    Best Temperature Measurement Accuracy±1% + 1 °C
    Best AC Voltage Accuracy±1% + 4 Digits
    Battery Type9V
    Best Resistance Measurement Accuracy±1% + 3 Digits
    Length186mm
    Best DC Voltage Accuracy±0.1% + 1 Digit
    Maximum Operating Temperature+55°C
    Best Capacitance Measurement Accuracy±1% + 2 Digits
    Minimum Operating Temperature-20°C
    Height31mm
    Battery Life400 h
    Weight355g
    Best DC Current Accuracy±0.4% + 2 Digits
    Safety Category Voltage664 V, 1000V
