Gossen Metrawatt M246B Handheld Digital Multimeter, True RMS, 10A ac Max, 10A dc Max, 1000V ac Max - UKAS Calibrated
- RS Stock No.:
- 192-5940
- Mfr. Part No.:
- M246B
- Brand:
- Gossen Metrawatt
Subtotal (1 unit)*
£965.91
(exc. VAT)
£1,159.09
(inc. VAT)
FREE delivery for orders over £50.00
- 4 unit(s) ready to ship from another location
Units | Per unit |
|---|---|
| 1 + | £965.91 |
*price indicative
- RS Stock No.:
- 192-5940
- Mfr. Part No.:
- M246B
- Brand:
- Gossen Metrawatt
Select all | Attribute | Value |
|---|---|---|
| Brand | Gossen Metrawatt | |
| Multimeter Type | Handheld | |
| Model Number p | M246B | |
| Display Type | Digital | |
| Calibrated | UKAS | |
| Functions Measured | AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature | |
| Absolute Maximum AC Current Measurement | 10A ac | |
| Absolute Maximum Resistance Measurement | 30MΩ | |
| Absolute Maximum DC Current Measurement | 10A dc | |
| Absolute Maximum AC Voltage Measurement | 1000V ac | |
| Absolute Maximum DC Voltage Measurement | 1000V dc | |
| True RMS | Yes | |
| Absolute Maximum Capacitance Measurement | 300µF | |
| Maximum Frequency | 1MHz | |
| DC Current Measurement Resolution | 100nA dc | |
| AC Current Measurement Resolution | 100nA ac | |
| Resistance Measurement Resolution | 10mΩ | |
| AC Voltage Measurement Resolution | 10µV ac | |
| DC Voltage Measurement Resolution | 10µV dc | |
| Capacitance Measurement Resolution | 10pF | |
| Safety Category Level | CAT II, CAT III | |
| Temperature Measurement Resolution | 0.1°C | |
| Best Resistance Measurement Accuracy | 1 % | |
| Battery Type | 1.5 V AA Alkaline Manganese LR6 | |
| Safety Category Voltage | 600 V, 1000V | |
| Maximum Operating Temperature | +50°C | |
| Best AC Voltage Accuracy | 1 % | |
| Best Temperature Measurement Accuracy | 1 % | |
| Best DC Voltage Accuracy | 1 % | |
| Dimensions | 87 x 45 x 200mm | |
| Best Capacitance Measurement Accuracy | 1 % | |
| Width | 45mm | |
| Best AC Current Accuracy | 1 % | |
| Best DC Current Accuracy | 1 % | |
| Height | 200mm | |
| Minimum Operating Temperature | -10°C | |
| Length | 87mm | |
Select all | ||
|---|---|---|
Brand Gossen Metrawatt | ||
Multimeter Type Handheld | ||
Model Number p M246B | ||
Display Type Digital | ||
Calibrated UKAS | ||
Functions Measured AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature | ||
Absolute Maximum AC Current Measurement 10A ac | ||
Absolute Maximum Resistance Measurement 30MΩ | ||
Absolute Maximum DC Current Measurement 10A dc | ||
Absolute Maximum AC Voltage Measurement 1000V ac | ||
Absolute Maximum DC Voltage Measurement 1000V dc | ||
True RMS Yes | ||
Absolute Maximum Capacitance Measurement 300µF | ||
Maximum Frequency 1MHz | ||
DC Current Measurement Resolution 100nA dc | ||
AC Current Measurement Resolution 100nA ac | ||
Resistance Measurement Resolution 10mΩ | ||
AC Voltage Measurement Resolution 10µV ac | ||
DC Voltage Measurement Resolution 10µV dc | ||
Capacitance Measurement Resolution 10pF | ||
Safety Category Level CAT II, CAT III | ||
Temperature Measurement Resolution 0.1°C | ||
Best Resistance Measurement Accuracy 1 % | ||
Battery Type 1.5 V AA Alkaline Manganese LR6 | ||
Safety Category Voltage 600 V, 1000V | ||
Maximum Operating Temperature +50°C | ||
Best AC Voltage Accuracy 1 % | ||
Best Temperature Measurement Accuracy 1 % | ||
Best DC Voltage Accuracy 1 % | ||
Dimensions 87 x 45 x 200mm | ||
Best Capacitance Measurement Accuracy 1 % | ||
Width 45mm | ||
Best AC Current Accuracy 1 % | ||
Best DC Current Accuracy 1 % | ||
Height 200mm | ||
Minimum Operating Temperature -10°C | ||
Length 87mm | ||
