RS PRO LCD, TFT Colour Multimeter, True RMS, 20mA ac Max, 10A dc Max, 1000V ac Max

View all Multimeters

Subtotal (1 unit)*

£161.87

(exc. VAT)

£194.24

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 41 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£161.87

*price indicative

Calibration Options:

presentation
RS PRO LCD, TFT Colour Multimeter, True RMS, 20mA ac Max, 10A dc Max, 1000V ac Max
Calibration Type:
RSCAL
RS Stock No.
360-202

Each

£227.66

(exc. VAT)

£273.19

(inc. VAT)

presentation
RS PRO LCD, TFT Colour Multimeter, True RMS, 20mA ac Max, 10A dc Max, 1000V ac Max
Calibration Type:
UKAS
RS Stock No.
360-203

Each

£255.60

(exc. VAT)

£306.72

(inc. VAT)

RS Stock No.:
360-200
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Multimeter Type

Digital

Display Type

LCD, TFT Colour

Functions Measured

AC Current, AC Voltage, Auto Resistance, Capacitance, DC Voltage, Frequency, Resistance

Absolute Maximum AC Current Measurement

20mA ac

Absolute Maximum AC Voltage Measurement

1000V ac

Absolute Maximum DC Current Measurement

10A dc

Absolute Maximum DC Voltage Measurement

1000V dc

Absolute Maximum Capacitance Measurement

10mF

True RMS

Yes

Absolute Maximum Temperature Measurement

+1350°C

Maximum Frequency

10MHz

DC Current Measurement Resolution

10µA

AC Current Measurement Resolution

10µA

AC Voltage Measurement Resolution

10mV

Resistance Measurement Resolution

10mΩ

DC Voltage Measurement Resolution

10mV

Temperature Measurement Resolution

0.1°C

Capacitance Measurement Resolution

0.001nF

Best AC Current Accuracy

±0.8%

Best Capacitance Measurement Accuracy

±1%

Length

50mm

Maximum Operating Temperature

40°C

Battery Type

7.4V - NEDA 1604

Best DC Voltage Accuracy

±0.05%

Best AC Voltage Accuracy

±0.5%

Minimum Operating Temperature

5°C

Height

170mm

Weight

360g

Best DC Current Accuracy

±0.2%

Best Resistance Measurement Accuracy

±0.2%

Best Temperature Measurement Accuracy

±1%

Width

79mm

COO (Country of Origin):
CN

RS PRO True RMS Multimeter, 50,000 Count


The RS PRO True RMS Multimeter is a robust digital device designed for precise measurement tasks in industrial environments. With its high-resolution TFT colour LCD display, it offers fast and accurate readings, making it ideal for troubleshooting and monitoring equipment. The multimeter's built-in data logging and trend capture features enhance its utility by allowing users to track and analyse equipment performance over time.

Features and Benefits


Large 50,000 count display for detailed measurement readings
320 x 240 TFT colour LCD for clear visibility in various lighting conditions
Logging function with trend capture for easy review of logged data
Bluetooth interface for seamless data transfer and remote monitoring
Accuracy calibration with 10kHz bandwidth for precise voltage and current measurements
True RMS measurements for accurate AC, ACV+DCV readings
Records events and trends to help identify equipment issues
2m drop proof design for enhanced durability in industrial settings

Applications


Industrial equipment troubleshooting
Electrical maintenance and repair
Data logging and analysis

Additional Information


Includes Meterbox Pro & cloud service for data management
Double molded plastic housing for safer measurements

Why RS PRO?


RS PRO is the own brand of RS, offering professional quality products and solutions across all industries and technologies. Our product range is rigorously tested, inspected, and audited against demanding international standards to provide you with industrial-grade quality, at the right price. Making RS PRO your smart choice.

Multimeter cable, multimeter case and a multimeter bracket on a burgundy background
