Infineon IPT Type N-Channel MOSFET, 174 A, 150 V, 16-Pin TO-263 IPTC044N15NM5ATMA1
- RS Stock No.:
- 260-2672
- Mfr. Part No.:
- IPTC044N15NM5ATMA1
- Brand:
- Infineon
Bulk discount available
Subtotal (1 unit)*
£5.70
(exc. VAT)
£6.84
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 180 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £5.70 |
| 10 - 24 | £5.13 |
| 25 - 49 | £4.79 |
| 50 - 99 | £4.51 |
| 100 + | £4.16 |
*price indicative
- RS Stock No.:
- 260-2672
- Mfr. Part No.:
- IPTC044N15NM5ATMA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Product Type | MOSFET | |
| Channel Type | Type N | |
| Maximum Continuous Drain Current Id | 174A | |
| Maximum Drain Source Voltage Vds | 150V | |
| Package Type | TO-263 | |
| Series | IPT | |
| Pin Count | 16 | |
| Maximum Drain Source Resistance Rds | 4.4mΩ | |
| Maximum Power Dissipation Pd | 300W | |
| Typical Gate Charge Qg @ Vgs | 71nC | |
| Maximum Gate Source Voltage Vgs | 20 V | |
| Forward Voltage Vf | 0.82V | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 175°C | |
| Standards/Approvals | RoHS, IEC 61249-2-21 | |
| Length | 10.1mm | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Product Type MOSFET | ||
Channel Type Type N | ||
Maximum Continuous Drain Current Id 174A | ||
Maximum Drain Source Voltage Vds 150V | ||
Package Type TO-263 | ||
Series IPT | ||
Pin Count 16 | ||
Maximum Drain Source Resistance Rds 4.4mΩ | ||
Maximum Power Dissipation Pd 300W | ||
Typical Gate Charge Qg @ Vgs 71nC | ||
Maximum Gate Source Voltage Vgs 20 V | ||
Forward Voltage Vf 0.82V | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 175°C | ||
Standards/Approvals RoHS, IEC 61249-2-21 | ||
Length 10.1mm | ||
Automotive Standard No | ||
The Infineon MOSFET provides a cooling package for superior thermal performance with an innovative package combined with the key features of the technology which allows best in class products as well as high current rating for high-power density designs.
Minimized thermal resistance to heatsink
Increased system efficiency enabling extended battery life time
High power density
Superior thermal performance
Saving in cooling system
