Infineon HEXFET MOSFET, 150 A, 30 V TO-220 IRLB4132PBF
- RS Stock No.:
- 258-3994
- Mfr. Part No.:
- IRLB4132PBF
- Brand:
- Infineon
Bulk discount available
Subtotal (1 pack of 5 units)*
£2.76
(exc. VAT)
£3.31
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 1,240 unit(s) shipping from 29 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 45 | £0.552 | £2.76 |
| 50 - 120 | £0.492 | £2.46 |
| 125 - 245 | £0.458 | £2.29 |
| 250 - 495 | £0.432 | £2.16 |
| 500 + | £0.396 | £1.98 |
*price indicative
- RS Stock No.:
- 258-3994
- Mfr. Part No.:
- IRLB4132PBF
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Product Type | MOSFET | |
| Maximum Continuous Drain Current Id | 150A | |
| Maximum Drain Source Voltage Vds | 30V | |
| Package Type | TO-220 | |
| Series | HEXFET | |
| Mount Type | Surface | |
| Maximum Drain Source Resistance Rds | 4.5mΩ | |
| Typical Gate Charge Qg @ Vgs | 36nC | |
| Forward Voltage Vf | 1.2V | |
| Minimum Operating Temperature | -55°C | |
| Maximum Gate Source Voltage Vgs | 20 V | |
| Maximum Power Dissipation Pd | 140W | |
| Maximum Operating Temperature | 175°C | |
| Standards/Approvals | Lead-Free, RoHS | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Product Type MOSFET | ||
Maximum Continuous Drain Current Id 150A | ||
Maximum Drain Source Voltage Vds 30V | ||
Package Type TO-220 | ||
Series HEXFET | ||
Mount Type Surface | ||
Maximum Drain Source Resistance Rds 4.5mΩ | ||
Typical Gate Charge Qg @ Vgs 36nC | ||
Forward Voltage Vf 1.2V | ||
Minimum Operating Temperature -55°C | ||
Maximum Gate Source Voltage Vgs 20 V | ||
Maximum Power Dissipation Pd 140W | ||
Maximum Operating Temperature 175°C | ||
Standards/Approvals Lead-Free, RoHS | ||
Automotive Standard No | ||
The Infineon HEXFET power MOSFET optimized for broadest availability from distribution partners. Its product qualification according to JEDEC standard.
Optimized for 5V gate-drive voltage
Industry standard through-hole power package
High-current carrying capability package
