STMicroelectronics STO67N60DM6 Type N-Channel MOSFET, 33 A, 600 V Enhancement, 3-Pin TO-220 STO67N60DM6

View all MOSFETs

Subtotal (1 pack of 2 units)*

£9.66

(exc. VAT)

£11.60

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 60 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
2 +£4.83£9.66

*price indicative

Packaging Options:
RS Stock No.:
206-8631
Mfr. Part No.:
STO67N60DM6
Brand:
STMicroelectronics
Find similar products by selecting one or more attributes.
Select all

Brand

STMicroelectronics

Channel Type

Type N

Product Type

MOSFET

Maximum Continuous Drain Current Id

33A

Maximum Drain Source Voltage Vds

600V

Package Type

TO-220

Series

STO67N60DM6

Mount Type

Surface

Pin Count

3

Maximum Drain Source Resistance Rds

59mΩ

Channel Mode

Enhancement

Maximum Power Dissipation Pd

150W

Forward Voltage Vf

1.6V

Minimum Operating Temperature

-55°C

Typical Gate Charge Qg @ Vgs

72.5nC

Maximum Gate Source Voltage Vgs

25 V

Maximum Operating Temperature

150°C

Height

2.2mm

Length

11.48mm

Width

9.8 mm

Standards/Approvals

No

Automotive Standard

No

The STMicroelectronics high-voltage N-channel Power MOSFET is part of the MDmesh DM6 fast recovery diode series. Compared with the previous MDmesh fast generation, DM6 combines very low recovery charge (Qrr), recovery time (trr) and excellent improvement in RDS(on) per area with one of the most effective switching behaviours available in the market for the most demanding high-efficiency bridge topologies and ZVS phase-shift converters.

Fast-recovery body diode

Lower RDS(on) per area vs previous generation

Low gate charge, input capacitance and resistance

100% avalanche tested

Extremely high dv/dt ruggedness

Zener-protected

Excellent switching performance thanks to the extra driving source pin
