Infineon OptiMOS™ 5 N-Channel MOSFET, 80 A, 80 V, 8-Pin TDSON BSC070N10NS5ATMA1
- RS Stock No.:
- 171-1963
- Mfr. Part No.:
- BSC070N10NS5ATMA1
- Brand:
- Infineon
Bulk discount available
Subtotal (1 pack of 10 units)*
£8.41
(exc. VAT)
£10.09
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 4,200 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 10 - 40 | £0.841 | £8.41 |
| 50 - 90 | £0.673 | £6.73 |
| 100 - 240 | £0.631 | £6.31 |
| 250 - 490 | £0.589 | £5.89 |
| 500 + | £0.547 | £5.47 |
*price indicative
- RS Stock No.:
- 171-1963
- Mfr. Part No.:
- BSC070N10NS5ATMA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Channel Type | N | |
| Maximum Continuous Drain Current | 80 A | |
| Maximum Drain Source Voltage | 80 V | |
| Package Type | TDSON | |
| Series | OptiMOS™ 5 | |
| Mounting Type | Surface Mount | |
| Pin Count | 8 | |
| Maximum Drain Source Resistance | 10.2 mΩ | |
| Channel Mode | Enhancement | |
| Maximum Gate Threshold Voltage | 3.8V | |
| Minimum Gate Threshold Voltage | 2.2V | |
| Maximum Power Dissipation | 83 W | |
| Transistor Configuration | Single | |
| Maximum Gate Source Voltage | 20 V | |
| Length | 5.49mm | |
| Number of Elements per Chip | 1 | |
| Width | 6.35mm | |
| Maximum Operating Temperature | +150 °C | |
| Typical Gate Charge @ Vgs | 30 nC @ 10 V | |
| Minimum Operating Temperature | -55 °C | |
| Height | 1.1mm | |
| Forward Diode Voltage | 1.1V | |
Select all | ||
|---|---|---|
Brand Infineon | ||
Channel Type N | ||
Maximum Continuous Drain Current 80 A | ||
Maximum Drain Source Voltage 80 V | ||
Package Type TDSON | ||
Series OptiMOS™ 5 | ||
Mounting Type Surface Mount | ||
Pin Count 8 | ||
Maximum Drain Source Resistance 10.2 mΩ | ||
Channel Mode Enhancement | ||
Maximum Gate Threshold Voltage 3.8V | ||
Minimum Gate Threshold Voltage 2.2V | ||
Maximum Power Dissipation 83 W | ||
Transistor Configuration Single | ||
Maximum Gate Source Voltage 20 V | ||
Length 5.49mm | ||
Number of Elements per Chip 1 | ||
Width 6.35mm | ||
Maximum Operating Temperature +150 °C | ||
Typical Gate Charge @ Vgs 30 nC @ 10 V | ||
Minimum Operating Temperature -55 °C | ||
Height 1.1mm | ||
Forward Diode Voltage 1.1V | ||
The Infineon BSC070N10NS5 is the 100V OptiMOS 5 power MOSFET in TOLL. This MOSFET is optimized for synchronous rectification and ideal for high switching frequency. This MOSFET have highest system efficiency and reduced switching and conduction losses.
Optimized for high performance SMPS
100% avalanche tested
Superior thermal resistance
N-channel
100% avalanche tested
Superior thermal resistance
N-channel
