ABB Temperature Monitoring Relay, 1 Phase, DPDT, DIN Rail
- RS Stock No.:
- 876-5042
- Mfr. Part No.:
- 1SVR740712R2200 CM-MSS.33P
- Brand:
- ABB
2 In stock - FREE next working day delivery available
2 In stock - FREE next working day delivery available
Price Each
£80.48
(exc. VAT)
£96.58
(inc. VAT)
Units | Per unit |
|---|---|
| 1 - 4 | £80.48 |
| 5 + | £77.20 |
- RS Stock No.:
- 876-5042
- Mfr. Part No.:
- 1SVR740712R2200 CM-MSS.33P
- Brand:
- ABB
Technical Reference
Legislation and Compliance
Product Details
CM-MSS Series Thermistor Motor Protection Relays
Heavy duty starting
Increased switching frequency
High ambient temperature
Insufficient cooling
Break operation
Unbalance
Increased switching frequency
High ambient temperature
Insufficient cooling
Break operation
Unbalance
The CM range of thermistor motor protection relays are used to control motors equipped with PTC temperature sensors. The PTC temperature sensors are incorporated in the motor windings to measure the motor heating. This enables direct control and evaluation of the following operating conditions:
Main features include:
Dynamic interrupted wire detection
Wide control supply voltage range for this series 24-240 V AC/DC
Short circuit monitoring of the sensor circuit
Non-volatile fault storage
Remote reset
Screw connection technology or Easy Connect Technology available
Dynamic interrupted wire detection
Wide control supply voltage range for this series 24-240 V AC/DC
Short circuit monitoring of the sensor circuit
Non-volatile fault storage
Remote reset
Screw connection technology or Easy Connect Technology available
Single Sensor Input Version
Wire Break Detection
Wire Break Detection
Approvals
Some products also have the ATEX approval for the use in hazardous areas.
Specifications
Attribute | Value |
|---|---|
| Monitoring Application | Temperature |
| Electrical Phase | 1 |
| Contact Configuration | DPDT |
| Mounting Type | DIN Rail |
| Time Delay | <100ms |
| Temperature Sensitivity | Overtemperature, Winding Temperature |
| Series | CM-MSS |
| Hazardous Area Certification | ATEX |
| Operating Temperature Range | +60°C |
| Length | 103.7mm |
| Maximum Operating Temperature | +60°C |
| Width | 22.5mm |
| Minimum Operating Temperature | -25°C |
| Current Range | Maximum of 3.7mA |
| Dimensions | 103.7 x 22.5 x 85.6mm |
| Special Features | Fail-Safe, Inbuilt PTC Sensor, Insufficient Cooling Protection, Manual & Automatic Reset, One Measuring Circuit, Over Heating Protection, Over Load Protection, Remote Reset, Short-Circuit Monitoring of the Sensor Circuit, Test and Reset Button |
| Number of Poles | 1 |
| Height | 85.6mm |
| Terminal Type | Push In |
