Eaton xPole MCB, 3P, 63A Curve C, 400V AC, 48V DC, 10 kA Breaking Capacity
- RS Stock No.:
- 864-4415
- Mfr. Part No.:
- 242480 PLSM-C63/3-MW
- Brand:
- Eaton
Subtotal (1 unit)*
£91.80
(exc. VAT)
£110.16
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 5 unit(s) ready to ship from another location
- Plus 7 unit(s) shipping from 13 October 2025
- Plus 9 unit(s) shipping from 28 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £91.80 |
*price indicative
- RS Stock No.:
- 864-4415
- Mfr. Part No.:
- 242480 PLSM-C63/3-MW
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 3 | |
| Current Rating | 63A | |
| Tripping Characteristics | Type C | |
| Rated AC Voltage | 400V | |
| Rated DC Voltage | 48V | |
| Breaking Capacity at Maximum Voltage Rating | 10 kA | |
| Range | xPole | |
| Circuit Breaker Type | MCB | |
| Length | 52.5mm | |
| Width | 80mm | |
| Mounting Style | DIN Rail Mount | |
| Depth | 75mm | |
| Model Number | 242480 | |
| Application | Commercial, Residential | |
Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 3 | ||
Current Rating 63A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 400V | ||
Rated DC Voltage 48V | ||
Breaking Capacity at Maximum Voltage Rating 10 kA | ||
Range xPole | ||
Circuit Breaker Type MCB | ||
Length 52.5mm | ||
Width 80mm | ||
Mounting Style DIN Rail Mount | ||
Depth 75mm | ||
Model Number 242480 | ||
Application Commercial, Residential | ||
RoHS Status: Not Applicable
PLSM MW Series, C Characteristic, 3 Pole
Versatile, safe and high-quality miniature circuit breakers for commercial and residential applications
Contact position indicator red - green
Guide for secure terminal connection
3-position DIN rail clip, permits removal from existing busbar system
Rated currents up to 63 A
Rated breaking capacity 10 kA according to IEC/EN 60898-1
Meets the requirements of insulation co-ordination, distance between contacts ≥ 4 mm, for secure isolation
Guide for secure terminal connection
3-position DIN rail clip, permits removal from existing busbar system
Rated currents up to 63 A
Rated breaking capacity 10 kA according to IEC/EN 60898-1
Meets the requirements of insulation co-ordination, distance between contacts ≥ 4 mm, for secure isolation
Eaton 3-Pole MCB, 400V Voltage Rating, 10kA Breaking Capacity - PLSM Series - 242480 PLSM-C63/3-MW
Features & Benefits
• Current rating of 63A for use in high-power applications
• Rated impulse withstand voltage of 4kV to handle sudden voltage surges
• Type-C tripping characteristics to cut power at 5 to 10 times the rated current and protect sensitive equipment
• Green and red indicators to quickly identify 'on' and 'off' positions
• Rated impulse withstand voltage of 4kV to handle sudden voltage surges
• Type-C tripping characteristics to cut power at 5 to 10 times the rated current and protect sensitive equipment
• Green and red indicators to quickly identify 'on' and 'off' positions
How do I reset this circuit breaker after it's tripped?
The circuit breaker has a toggle switch that you can use to re-actuate it after it's tripped.
Is this MCB waterproof?
This MCB isn't waterproof and must be kept away from sources of moisture to ensure optimal performance.
Note
Eaton formerly known as Moeller
Moeller — circuit breaker
