Eaton xPole MCB, 1P, 6A Curve C, 48V DC, 10 kA Breaking Capacity
- RS Stock No.:
- 864-4314
- Mfr. Part No.:
- 242200 PLSM-C6-MW
- Brand:
- Eaton
Subtotal (1 unit)*
£22.61
(exc. VAT)
£27.13
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship
- Plus 11 unit(s) ready to ship from another location
- Plus 12 unit(s) shipping from 13 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £22.61 |
*price indicative
- RS Stock No.:
- 864-4314
- Mfr. Part No.:
- 242200 PLSM-C6-MW
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Eaton | |
Number of Poles | 1 | |
Current Rating | 6A | |
Tripping Characteristics | Type C | |
Rated DC Voltage | 48V | |
Breaking Capacity at Maximum Voltage Rating | 10 kA | |
Range | xPole | |
Circuit Breaker Type | MCB | |
Length | 17.5mm | |
Width | 80mm | |
Mounting Style | DIN Rail Mount | |
Depth | 75mm | |
Select all | ||
---|---|---|
Brand Eaton | ||
Number of Poles 1 | ||
Current Rating 6A | ||
Tripping Characteristics Type C | ||
Rated DC Voltage 48V | ||
Breaking Capacity at Maximum Voltage Rating 10 kA | ||
Range xPole | ||
Circuit Breaker Type MCB | ||
Length 17.5mm | ||
Width 80mm | ||
Mounting Style DIN Rail Mount | ||
Depth 75mm | ||
RoHS Status: Not Applicable
Eaton MCB, 1.5W Heat Dissipation, Thermoplastic Housing - PLSM Series - 242200 PLSM-C6-MW
Use this MCB from Eaton to stop electrical faults in their tracks. It uses a thermal-magnetic protection mechanism to shield your equipment from both short circuits and overcurrents, which cuts out downtime and keeps you safe from the risk of fire. Thanks to durable thermoplastic housing, this piece of kit can handle mechanical impact without losing form. The material's also an insulator, so you won't get any nasty shocks when touching it. You can install this unit in a jiffy by simply clipping it onto a DIN rail. It's a must-have in your residential and commercial circuit setups.
Features & Benefits
• Narrow width of 17.5mm to fit easily into setups where space is at a premium
• Breaking capacity of 10kA means it can handle heavy current surges without suffering damage
• Broad operating temperature range between -25°C and +75°C for use in challenging conditions
• Breaking capacity of 10kA means it can handle heavy current surges without suffering damage
• Broad operating temperature range between -25°C and +75°C for use in challenging conditions
Is this MCB finger-safe?
Yes, this device has an IP20 rating and its terminals are located away from your fingers to make sure you can't accidentally touch live parts when installing or operating it.
Note
Eaton formerly known as Moeller
Moeller — circuit breaker
