Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	ABB
	Number of Poles	3
	Current Rating	20A
	Tripping Characteristics	Type C
	Rated AC Voltage	440V
	Breaking Capacity at Maximum Voltage Rating	6 kA
	Range	Compact Home
	Series	SH200
	Circuit Breaker Type	MCB
	Width	52.5mm
	Length	85mm
	Mounting Style	DIN Rail Mount
	Depth	69mm
	Model Number	SH203-C20
	Better World Claim	Designed for disassembly
	Better World Product	Yes
	Reset Actuator Type	Toggle Switch
	Application	Residential
	Terminal Contact Type	Screw Clamp

	Select all
	Brand ABB
	Number of Poles 3
	Current Rating 20A
	Tripping Characteristics Type C
	Rated AC Voltage 440V
	Breaking Capacity at Maximum Voltage Rating 6 kA
	Range Compact Home
	Series SH200
	Circuit Breaker Type MCB
	Width 52.5mm
	Length 85mm
	Mounting Style DIN Rail Mount
	Depth 69mm
	Model Number SH203-C20
	Better World Claim Designed for disassembly
	Better World Product Yes
	Reset Actuator Type Toggle Switch
	Application Residential
	Terminal Contact Type Screw Clamp

COO (Country of Origin):: DE

ABB SH200 Series MCB, 3 Poles, 20A Current Rating - 2CDS213001R0204 SH203-C20

This miniature circuit breaker (MCB) provides essential electrical protection for both residential and industrial applications. Featuring a 3-pole configuration and rated at 20A, it is designed for a variety of load conditions. The advanced mechanisms help enhance safety by preventing overload and short circuits, thereby protecting your electrical systems efficiently.

Features & Benefits

• Offers Type C characteristics suitable for high inrush currents
• Rated for 440V, making it adaptable to various uses
• Compact design facilitates easy installation on DIN rail
• Current limiting feature safeguards sensitive electrical devices
• Designed for disassembly, supporting environmentally friendly practices
• 6kA breaking capacity ensures effective fault protection

Applications

• Suitable for residential electrical systems to improve safety
• Ideal for industrial settings requiring consistent overload protection
• Applicable in automation systems where electrical integrity is vital
• Commonly used in mechanical setups needing short circuit prevention

How does this product protect against electrical faults?

It utilises delayed thermal tripping for overloads and electromechanical mechanisms for short circuits.

What is the maximum voltage it can handle?

It is rated for a maximum operational voltage of 440V AC.

Can it be installed in any position?

Yes, it can be installed in any position on the DIN rail.

What type of wiring is compatible with this device?

It accommodates various conductor sizes, including flexible and rigid wires.

Is there a need for regular maintenance?

Routine checks are recommended to ensure ongoing reliability and safety.

Standards

BS EN 60898

ABB Compact Home

ABB Compact Home SH200 MCB, 3P, 20A Curve C, 440V AC, 6 kA Breaking Capacity
