Eaton xEffect FAZ Miniature Circuit Breaker, 3-Pole, 2 A, Type D, 415 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 240-483
- Mfr. Part No.:
- 102300 FAZ-D2/3-RT
- Brand:
- Eaton
Subtotal (1 unit)*
£238.39
(exc. VAT)
£286.07
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 06 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £238.39 |
*price indicative
- RS Stock No.:
- 240-483
- Mfr. Part No.:
- 102300 FAZ-D2/3-RT
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 3 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 2 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 415 V ac | |
| Rated DC Voltage | 60 V | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 15kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20, IP40 | |
| Standards/Approvals | CSA-C22.2 No. 5-09, CE marking, CSA C22.2 No. 5, CSA (Class No. 1432-01), CSA (File No. 204453), EN45545-2, IEC 60947-2, IEC 61373, IEC/EN 60947-2, North America (UL,CSA ), Specially designed for North America, suitable as BCPD, UL 489, UL (Category Control Number DIVQ), UL (File No. E235139) | |
| Width | 53.1 mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 3 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 2 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 415 V ac | ||
Rated DC Voltage 60 V | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 15kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20, IP40 | ||
Standards/Approvals CSA-C22.2 No. 5-09, CE marking, CSA C22.2 No. 5, CSA (Class No. 1432-01), CSA (File No. 204453), EN45545-2, IEC 60947-2, IEC 61373, IEC/EN 60947-2, North America (UL,CSA ), Specially designed for North America, suitable as BCPD, UL 489, UL (Category Control Number DIVQ), UL (File No. E235139) | ||
Width 53.1 mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series is designed to ensure superior protection in industrial and advanced commercial applications. With a tripping characteristic of D and a rated current of 2 A, it effectively safeguards feeder and branch circuits from overloads and short circuits. The compact dimensions of 105 mm in length and 53.1 mm in width make it an ideal choice for environments with space constraints. Its innovative design incorporates essential features like IP20 protection when uninstalled and IP40 when fitted, ensuring that it remains operational in diverse conditions.
Dual voltage ratings for AC and DC applications
High tripping capacity ensures reliable operation
Environmentally compliant promoting sustainability
Robust terminal protection ensures safety during installation
Fast installation with top hat rail mounting method
Optimizes thermal stability and operation within prescribed temperature ranges
