Eaton xEffect FAZ Miniature Circuit Breaker, 3-Pole, 2 A, Type D, 415 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 248-632
- Mfr. Part No.:
- 102260 FAZ-D2/3-NA
- Brand:
- Eaton
Subtotal (1 unit)*
£233.72
(exc. VAT)
£280.46
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 20 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £233.72 |
*price indicative
- RS Stock No.:
- 248-632
- Mfr. Part No.:
- 102260 FAZ-D2/3-NA
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 3 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 2 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 415 V ac | |
| Rated DC Voltage | 60 V | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 15kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20 | |
| Standards/Approvals | RoHS IEC 60947 CSA (Class . 1401) UL (File . E519) UL 489, CSA C. . 5 CSA (File . 0445) CE CSAC. . 509 IECEN 60947 UL 489 EN45545 IEC 617 | |
| Depth | 105mm | |
| Height | 75.5mm | |
| Width | 53.1 mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 3 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 2 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 415 V ac | ||
Rated DC Voltage 60 V | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 15kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20 | ||
Standards/Approvals RoHS IEC 60947 CSA (Class . 1401) UL (File . E519) UL 489, CSA C. . 5 CSA (File . 0445) CE CSAC. . 509 IECEN 60947 UL 489 EN45545 IEC 617 | ||
Depth 105mm | ||
Height 75.5mm | ||
Width 53.1 mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series specifically engineered to meet the stringent requirements of the North American market. Designed for three pole configurations, this device is constructed to deliver exceptional performance in feeder and branch circuit applications. With a robust tripping characteristic of D, it ensures high reliability and operational safety, essential for demanding environments.
High breaking capacity enhances safety standards
Compact dimensions facilitate easy integration into existing systems
Rated insulation voltage facilitates greater efficiency
Designed specifically for North American electrical compliance
Robust construction ensures longevity in demanding conditions
Finger and hand touch safe terminals enhance user safety
Wide range of conductor cross section compatibility maximises flexibility
