Eaton xEffect MCB, 3P, 2A Curve D, 240 → 415V AC, 10 kA Breaking Capacity
- RS Stock No.:
- 847-3541
- Mfr. Part No.:
- 278884 FAZ-D2/3
- Brand:
- Eaton
Available to back order for despatch 11/06/2024
Added
Price Each
£115.79
(exc. VAT)
£138.95
(inc. VAT)
| Units | Per unit |
| 1 + | £115.79 |
Alternatives
This product is not currently available. Here are our alternative recommendations.
Schneider Electric Acti 9 iC60H MCB, 3P, 2A Curve D, 440V AC, 100 → 133V DC, 10 kA Breaking Capacity
- RS Stock No.
- 791-3559
Price Each
£136.37
(exc. VAT)
£163.64
(inc. VAT)
- RS Stock No.:
- 847-3541
- Mfr. Part No.:
- 278884 FAZ-D2/3
- Brand:
- Eaton
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
Product Details
Eaton FAZ Series Circuit Breakers
The FAZ series by Eaton offers a wide range of quality, highly reliable and safe circuit breakers. Eaton’s FAZ DIN rail mountable circuit breaker is designed for use in control panel applications.
Features and Benefits
• The Eaton miniature circuit breaker has a current limiting design, providing short circuit interruption to reduce let-through energy, which can damage the circuit.
• Rated currents up to 63A.
• The toggle can be sealed in both the on and off position where required, and the trip-free design means that the breaker cannot be defeated by holding the handle in the on position.
• Reliable and safe operation with six levels of thermal-magnetic over-current protection.
• Red or green light indicates the contact position.
• Easy installation.
• Suitable for supplementary protection.
• Rated currents up to 63A.
• The toggle can be sealed in both the on and off position where required, and the trip-free design means that the breaker cannot be defeated by holding the handle in the on position.
• Reliable and safe operation with six levels of thermal-magnetic over-current protection.
• Red or green light indicates the contact position.
• Easy installation.
• Suitable for supplementary protection.
Note
Eaton formerly known as Moeller
Specifications
Attribute | Value |
|---|---|
| Number of Poles | 3P |
| Current Rating | 2A |
| Tripping Characteristics | Type D |
| Rated AC Voltage | 240 → 415V |
| Breaking Capacity at Maximum Voltage Rating | 10 kA |
| Range | xEffect |
| Series | Eaton Moeller |
| Circuit Breaker Type | MCB |
| Width | 85mm |
| Length | 54mm |
| Mounting Style | DIN Rail Mount |
| Depth | 73mm |
