Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 2 A, Type D, 240 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 243-539
- Mfr. Part No.:
- 102140 FAZ-D2/1-RT
- Brand:
- Eaton
Subtotal (1 unit)*
£76.55
(exc. VAT)
£91.86
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 06 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £76.55 |
*price indicative
- RS Stock No.:
- 243-539
- Mfr. Part No.:
- 102140 FAZ-D2/1-RT
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 1 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 2 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 240 V ac | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 15kA | |
| Mount Type | Top Hat Rail | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20 | |
| Standards/Approvals | EAN, CSA, EN45545-2, EN 63000:2018, IEC 61373, IEC/EN 60898, IEC/EN 60947-2, RoHS, UL | |
| Depth | 105mm | |
| Height | 75.5mm | |
| Width | 17.7 mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 1 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 2 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 240 V ac | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 15kA | ||
Mount Type Top Hat Rail | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20 | ||
Standards/Approvals EAN, CSA, EN45545-2, EN 63000:2018, IEC 61373, IEC/EN 60898, IEC/EN 60947-2, RoHS, UL | ||
Depth 105mm | ||
Height 75.5mm | ||
Width 17.7 mm | ||
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series is designed to provide superior protection for electrical circuits. Ideal for industrial and advanced commercial applications, it features a high breaking capacity, ensuring reliability even in demanding conditions. Its innovative thermal stability and impulse withstand voltage ratings enhance safety and performance, making it an essential component for any professional electrical panel.
Rated short circuit breaking capacity guarantees reliability during fault conditions
Environmentally friendly with RoHS compliance for sustainable usage
Available with top hat rail mounting for easy installation and flexibility
Finger and hand touch safe terminals enhance user safety during maintenance
Low heat dissipation ensures minimal energy loss during operation
Designed with UV resistance to withstand environmental exposure
