TE Connectivity 2 Pole Flange Switch Disconnector - 250A Maximum Current, IP6K9, IP67
- RS Stock No.:
- 170-729
- Mfr. Part No.:
- 35-210-041-S
- Brand:
- TE Connectivity
Subtotal (1 unit)*
£34.76
(exc. VAT)
£41.71
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 20 unit(s) shipping from 13 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £34.76 |
*price indicative
- RS Stock No.:
- 170-729
- Mfr. Part No.:
- 35-210-041-S
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Number of Poles | 2 | |
| Maximum Current | 250A | |
| Mounting Type | Flange | |
| IP Rating | IP6K9, IP67 | |
| Voltage Rating | 32V dc | |
| Handle Colour | Black | |
| Model Number | 35-210-041-S | |
| Auxiliary Contacts Available | No | |
| Series | KISSLING Series 35 | |
| Switch Rating | 250A | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +85°C | |
Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Number of Poles 2 | ||
Maximum Current 250A | ||
Mounting Type Flange | ||
IP Rating IP6K9, IP67 | ||
Voltage Rating 32V dc | ||
Handle Colour Black | ||
Model Number 35-210-041-S | ||
Auxiliary Contacts Available No | ||
Series KISSLING Series 35 | ||
Switch Rating 250A | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +85°C | ||
- COO (Country of Origin):
- SK
35-210-041-S
The TE Connectivity Manually operated battery disconnector up to 200 amps meets the most demanding requirements in all vehicle applications. The nominal current ratings refer to continuous DC current at up to 100% duty cycle and the switches are built to switch under full load.
Robust design
6G shock and 4G vibration resistant
Sealed housing conforms to IP6K9K
Battery disconnection under load in case of an emergency
6G shock and 4G vibration resistant
Sealed housing conforms to IP6K9K
Battery disconnection under load in case of an emergency
