Gossen Metrawatt M507C Insulation Measuring Instrument, 40 V Min, 5 kV Max, 0.100 mΩ CAT II, CAT III

RS Stock No.:: 260-8283
Mfr. Part No.:: M507C
Brand:: Gossen Metrawatt

Gossen Metrawatt M507C Insulation Measuring Instrument, 40 V Min, 5 kV Max, 0.100 mΩ CAT II, CAT III

Subtotal (1 unit)*

£557.16

(exc. VAT)

£668.59

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

Plus 1 unit(s) shipping from 09 November 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£557.16

*price indicative

RS Stock No.:: 260-8283
Mfr. Part No.:: M507C
Brand:: Gossen Metrawatt

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Gossen Metrawatt
	Product Type	Insulation Tester
	Model Number	M507C
	Tester Type	Insulation Measuring Instrument
	Minimum Test Voltage	40V
	Maximum Test Voltage	5kV
	Display Type	OLED
	Test Current	1mA
	Battery Type	AAA LR03, Nickel-Metal Hydride
	Power Source	Battery Power Supply
	Minimum Operating Temperature	0°C
	Insulation Testing Resistance	0.100mΩ
	Safety Category Voltage	300V
	Maximum Operating Temperature	40°C
	Safety Category Level	CAT II, CAT III
	Height	70mm
	Width	40mm
	Standards/Approvals	EN 613261:2006, EN 613261:2006 class B
	Length	260mm
	Weight	360g

	Select all
	Brand Gossen Metrawatt
	Product Type Insulation Tester
	Model Number M507C
	Tester Type Insulation Measuring Instrument
	Minimum Test Voltage 40V
	Maximum Test Voltage 5kV
	Display Type OLED
	Test Current 1mA
	Battery Type AAA LR03, Nickel-Metal Hydride
	Power Source Battery Power Supply
	Minimum Operating Temperature 0°C
	Insulation Testing Resistance 0.100mΩ
	Safety Category Voltage 300V
	Maximum Operating Temperature 40°C
	Safety Category Level CAT II, CAT III
	Height 70mm
	Width 40mm
	Standards/Approvals EN 613261:2006, EN 613261:2006 class B
	Length 260mm
	Weight 360g

COO (Country of Origin):: DE

Gossen-Metrawatt Insulation Tester, 1000V Maximum Test Voltage, 0.100mΩ Insulation Testing Resistance - M507C

This insulation tester is a battery-operated instrument designed to assess electrical insulation resistance across a broad voltage range. It uses an OLED display for clear readouts and is intended for industrial and maintenance environments where insulation integrity measurement is required. The unit operates within common ambient temperatures and conforms to recognised electromagnetic standards for laboratory and workshop settings.

Features and Benefits:

• 1mA test current delivers controlled stress during measurements
• 40V to 1000V range enables low-to-high voltage insulation checks
• 0.100mΩ resolution allows detection of small resistance changes
• Battery powered with AAA NiMH support facilitates field use
• CAT II and CAT III safety rating protects operators on site

Applications

• Suitable for verifying insulation on distribution equipment
• Ideal for preventative maintenance in industrial facilities
• Used with portable test kits for on-site diagnostics
• Can be used for commissioning electrical installations
• Suitable for routine insulation surveys in workshops
