STMicroelectronics STGWT30H60DFB IGBT, 60 A 600 V, 3-Pin TO-3P, Through Hole

View all IGBTs

Subtotal (1 pack of 2 units)*

£6.47

(exc. VAT)

£7.764

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 24 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
2 +£3.235£6.47

*price indicative

Packaging Options:
RS Stock No.:
860-7325
Mfr. Part No.:
STGWT30H60DFB
Brand:
STMicroelectronics
Find similar products by selecting one or more attributes.
Select all

Brand

STMicroelectronics

Maximum Continuous Collector Current

60 A

Maximum Collector Emitter Voltage

600 V

Maximum Gate Emitter Voltage

±20V

Maximum Power Dissipation

260 W

Package Type

TO-3P

Mounting Type

Through Hole

Channel Type

N

Pin Count

3

Transistor Configuration

Single

Dimensions

15.8 x 5 x 14.1mm

Minimum Operating Temperature

-55 °C

Maximum Operating Temperature

+175 °C

IGBT Discretes, STMicroelectronics



IGBT Discretes & Modules, STMicroelectronics


The Insulated Gate Bipolar Transistor or IGBT is a three-terminal power semiconductor device, noted for high efficiency and fast switching. The IGBT combines the simple gate-drive characteristics of the MOSFETs with the high-current and low–saturation-voltage capability of bipolar transistors by combining an isolated gate FET for the control input, and a bipolar power transistor as a switch, in a single device.
