STMicroelectronics STGD4H60DF Single Collector IGBT, 4 A 600 V, 3-Pin TO-252, Surface

View all IGBTs
Bulk discount available

Subtotal (1 pack of 2 units)*

£0.79

(exc. VAT)

£0.948

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 300 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
2 - 28£0.395£0.79
30 - 58£0.36£0.72
60 - 118£0.32£0.64
120 - 238£0.30£0.60
240 +£0.295£0.59

*price indicative

Packaging Options:
RS Stock No.:
287-7045
Mfr. Part No.:
STGD4H60DF
Brand:
STMicroelectronics
Find similar products by selecting one or more attributes.
Select all

Brand

STMicroelectronics

Maximum Continuous Collector Current Ic

4A

Product Type

IGBT

Maximum Collector Emitter Voltage Vceo

600V

Number of Transistors

1

Maximum Power Dissipation Pd

75W

Configuration

Single Collector

Package Type

TO-252

Mount Type

Surface

Pin Count

3

Maximum Collector Emitter Saturation Voltage VceSAT

1.7V

Maximum Gate Emitter Voltage VGEO

20 V

Minimum Operating Temperature

-55°C

Maximum Operating Temperature

175°C

Height

2.3mm

Width

6.7 mm

Length

1.7mm

Standards/Approvals

RoHS

Automotive Standard

No

COO (Country of Origin):
CN
The STMicroelectronics Trench gate field stop is an IGBT developed using an Advanced proprietary trench gate field stop structure. This device is part of the H series of IGBTs, which represent an optimum compromise between conduction and switching losses to maximize the efficiency of high switching frequency converters. Moreover, a slightly positive VCE(sat) temperature coefficient and very tight parameter distribution result in safer paralleling operation.

Low thermal resistance

Short circuit rated

Soft and fast recovery antiparallel diode
